Product Type	Pendant Light
Brand	Crystorama
Model	Southport 4803-SR
Number of Lights	3
Bulb Type	E12 Candelabra Base (not included)
Maximum Wattage	60W per bulb
Voltage	120V
Material	Steel, Glass Shades
Finish	Satin Rust (SR)
Overall Height	26 inches (adjustable)
Diameter	20 inches
Weight	8 lbs
Chain Length	36 inches (included)
Canopy Size	5 inches diameter
Dimmable	Yes (with compatible dimmer and bulbs)
Installation	Hardwired, wall-mounted junction box
Cleaning	Wipe with soft dry cloth; do not use harsh chemicals
Safety Rating	UL Listed for dry locations
Warranty	1-year limited warranty
Included Parts	Fixture, chain, canopy, mounting hardware, instructions

Frequently Asked Questions - Southport 4803-SR Crystorama

What type of bulbs does the Southport 4803-SR require?

This fixture uses E12 candelabra base bulbs with a maximum wattage of 60W each. Bulbs are not included.

Is the Southport 4803-SR dimmable?

Yes, it is dimmable when used with a compatible dimmer switch and dimmable bulbs.

Can I adjust the hanging height?

Yes, the included 36-inch chain is adjustable to suit your ceiling height. The fixture can be installed at different lengths.

What is the finish color 'SR'?

SR stands for Satin Rust, a warm, matte rust-toned finish.

Is this fixture suitable for damp locations?

No, it is UL Listed for dry locations only, such as living rooms, bedrooms, or dining areas.

How do I clean the Southport 4803-SR?

Turn off power and wipe with a soft dry cloth. Do not use abrasive cleaners or liquids.

Does the fixture come with installation instructions?

Yes, detailed installation instructions are included in the package.

What is the weight of this pendant light?

The fixture weighs approximately 8 lbs.

Can I install this on a sloped ceiling?

Yes, the chain allows for slope ceiling installation up to 45 degrees.

What is the warranty period?

Crystorama offers a 1-year limited warranty against manufacturing defects.

USER MANUAL Southport 4803-SR Crystorama

WARNING:

Electrical Danger

Turn Power Off

All electrical components must be

installed by a licensed electrician

in accordance with the National

Electric Code and the appropriate

local electrical codes.

You will need 3- Candelabra Base Bulb

40 Watts recommended 60 Watts Max.

USE LED BULBS FOR EXTENDED USE

The fixture is Damp rated

HOW TO INSTALL:

Place the fixture parts on a soft cloth-covered platform before installation of fixture.

1. Attach the mounting bar onto the outlet box.
2. Screw the Center column kit onto the Bottom kit.
3. Insert the center flowers into the sheath of each center stem.
4. Decide the desired hanging height and adjust the chain to the correct length.
5. Raise the fixture up and do the wire connection. Attach the canopy over the mounting bar and secure with collar ring.

WARNING: This product can expose you to Lead,

which is known to the State of California to cause cancer

and/or birth defects or reproductive harm. For more

information go to www.p65warnings.ca.gov

LIGHTING THE WAY FOR SIXTY YEARS

ASSEMBLY INSTRUCTION MODEL # 4803-SR

Part Number

Part Numbers

A.(2)-Wire connector

B. (1)-Mounting bar

C. (2)-Outlet box screw

D. (1)-Lock washer

E. (1)-Hex nut

F. (1)-Nipple

G.(1)-Canopy (W5 3/8"xH1 3/8")-XSN4803SRCAN5.375IN

H. (1)-Collar Ring

I. (1)-Collar Loop

J. (1)-Chain (3mmx72")-XSN4803SRCHA3.0MM

K. (1)-Center Column Kit Loop

L.(1)-Center Column Kit Top leaf x1.

Top Bobeche ; ∅3 1/8", no pin, 10.3mm center hole.

Center stem with sheaths ; ∅3/8", H10 5/8"

Center flower x2.

M. (3)-Candle sleeve ; H2"-XSN4803SRCDL2IN

N. (3)-Bobeche ; ∅3 1/8", no pin, 10.3mm center hole. -XSN4803SRBOB3.125IN

O. (1)-Bottom Kit 5"Arm x3.

Bottom flower x3.

Coupling.

Distributor box ; ∅2",H1 1/4"

Metal wire ring.

P. (1)-Finial-XSN4803SRFIN
