Product Type	Digital Timer
Brand	Taylor
Model	5852
Dimensions (approx.)	2.8 x 2.8 x 1.2 in (7 x 7 x 3 cm)
Weight (approx.)	3.5 oz (100 g)
Power Source	1 AAA battery (not included)
Display	LCD digital display
Maximum Countdown Time	99 minutes 59 seconds
Alarm	Audible beep, 60 seconds duration
Memory Function	Yes, recalls last set time
Pause/Resume	Yes
Magnetic Back	Yes, for attachment to metal surfaces
Kickstand	Yes, for countertop use
Cleaning	Wipe with dry or slightly damp cloth. Do not immerse.
Safety	Keep away from water and high heat. Not for outdoor use.
Spare Parts	Replace battery as needed. No other user-serviceable parts.
Warranty	1 year limited warranty
Country of Origin	China

Frequently Asked Questions - 5852 Taylor

How do I set the countdown time?

Press the M button to set minutes and S button to set seconds. Then press Start/Stop to begin the countdown.

How do I reset the timer?

Press the Reset button (or M + S simultaneously) to return to the default time (00:00).

What type of battery does it use?

It requires one AAA alkaline battery (not included).

How long does the alarm sound?

The alarm beeps for approximately 60 seconds, then stops automatically.

Can I pause the timer?

Yes, press the Start/Stop button during countdown to pause. Press again to resume.

Does the timer have a memory function?

Yes, it remembers the last set time. Press M + S together to recall it.

How do I clean the timer?

Wipe the surface with a dry or slightly damp cloth. Do not use abrasive cleaners or immerse in water.

Can I use it outdoors?

It is designed for indoor use only. Keep away from moisture and extreme temperatures.

What is the maximum countdown time?

The maximum countdown time is 99 minutes 59 seconds.

Does the timer have a magnetic back?

Yes, it has a built-in magnet on the back for attachment to metal surfaces like refrigerators.

USER MANUAL 5852 Taylor

1. Press 'MIN' button to set minutes and 'SEC' button to set seconds.
2. Press 'START/STOP' to start countdown.
3. The time can be paused and restarted by pressing 'START/STOP'.
4. The alarm beeps when time is up, silence the timer by pressing the 'START/STOP' button. The alarm will reset to the last programmed time.
5. Press 'MIN' and 'SEC' together to reset the time to 00:00.
6. To count up: When the display is at 00:00 press 'START/STOP' to begin timing.

NOTE:

A plastic strip is used to prevent battery drain during shipping. Pull gently to remove before use. There is also a cling over the digital display, remove before use.

BATTERY PRECAUTIONS:

1. Batteries may pose a choking hazard, do not let children handle batteries.
2. Do not dispose of batteries in fire, they may explode or leak.
3. Remove batteries if product will not be used for a long period of time.
4. Always replace all batteries at the same time; do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc) or rechargeable (ni-cad, ni-mh, etc.) batteries.
5. Recycle or dispose of batteries per local regulations.

BATTERY REPLACEMENT:

Using a coin, turn the battery cover counterclockwise to open. Remove battery and replace with a new battery '+' side up. Replace battery cover.

CLEANING AND CARE:

Handwash only. Do not immerse in water or put in dishwasher.

ONE (1) YEAR WARRANTY (EXCLUDING BATTERIES)

BATTERY INCLUDED

MERCURY FREE BATTERY

For warranty information please call 1.866.843.3905 or visit us online at: SHOPTAYLORUSA.COM

58529.21.17

MODEL 5852

©2017 Taylor Precision Products Seattle, WA 98134

Place Sticker Here

Made in China

0 77784 03156 8
