Type of product	LED Signal Tower
Brand	PATLITE
Model	SKH-M2JB-R
Color	Red
Rated voltage	24 V DC
Power consumption	3 W
Light source	LED
Dimensions (diameter x height)	60 mm x 200 mm
Weight	200 g
Ingress protection rating	IP54
Operating temperature	-20°C to +50°C
Mounting type	Direct mounting or pole mounting
Connection method	Terminal block
Number of light modules	1
Flash rate	About 60 flashes per minute
Functions	Visual alarm indicator
Maintenance	Clean with soft dry cloth; do not use solvents
Safety precautions	Disconnect power before installation or maintenance; use only specified voltage
Spare parts availability	Replaceable LED module
Repairability	Modular design; replaceable parts
General information	Compact size, suitable for industrial signaling

Frequently Asked Questions - SKH-M2JB-R PATLITE

What voltage does the PATLITE SKH-M2JB-R require?

The PATLITE SKH-M2JB-R operates on 24 V DC.

How do I install the signal tower?

Mount the base securely using the provided bracket or pole mount. Connect the wires to the terminal block according to the wiring diagram. Ensure power is disconnected before installation.

Can the SKH-M2JB-R be used outdoors?

It has an IP54 rating, meaning it is protected against dust and splashing water. Suitable for sheltered outdoor use but not for heavy rain or hose-down.

What is the flash rate of this model?

The flash rate is approximately 60 flashes per minute when set to flashing mode.

Is the LED module replaceable?

Yes, the LED module is replaceable. Contact PATLITE or an authorized dealer for spare parts.

How do I clean the signal tower?

Use a soft dry cloth to wipe the surface. Do not use abrasive cleaners or solvents.

What is the operating temperature range?

The device can operate in temperatures from -20°C to +50°C.

Can I change the light color?

The SKH-M2JB-R is a red model. If you need a different color, check other models in the SKH series.

What is the power consumption?

The power consumption is approximately 3 W.

Does the unit include a buzzer?

No, this model is a light-only signal tower. For audible alarms, consider the SKH-M2 series with buzzer.

USER MANUAL SKH-M2JB-R PATLITE

INSTRUCTION MANUAL Rotating Beacons

TYPE SKS / SKH / SKP Multi-function Beacons

TYPE SF08 / SF10 Flashing Beacons

TYPE SL08 / SL10 / SL15

Notice to Customer

Thank you very much for purchasing our Patlite products.
- Request the installation and wiring be performed by a professional contractor if construction work is involved.
- Prior to installation, read this manual thoroughly before using this
product to ensure correct use.
- In addition, please store this manual for future performance maintenance repairs or inspections
•For options and repair parts, please visit our website
(https://www.patlite.com).
- If there are any questions concerning this product, refer to the contact information at the end of this document and contact company report.
Information at the end of this document and contact your nearest PATLITE Sales Representative.

1 Read this First (Safety Precautions)

Warning. Failure to observe the following may result in

Warning death or serious injury.
- To prevent from short-circuits or damage, observe the following:
- Be sure the power is disconnected before replacement or repair, including the replacement of the fuse.
- Use this product in a properly maintained condition. (Replace or repair if the
globe, case, etc. are damaged.)
- If installing this product requires construction work, ask a specialist in order to avoid fire, or personal injury.
- When this product is used for security purposes, it should be inspected daily.
In case a malfunction should occur, it is recommended that you use this product together with other security products.
- After installation, do not use this product to climb up onto the equipment with.

Failure to comply will result in product damage and/or falling off the machinery.

Caution Failure to comply with the following points may

Caution result in injury, physical loss or damage.

- Be sure to put a fuse in the wiring circuit between the power source and

equipment for protection. If a fuse is not added, it may result in product and/or equipment failure.

- Be sure to prevent electrostatic damage due to discharge when working with equipment failure.

this product for wiring, exchanging units, setting up parameters, etc. by discharging static electricity (e.g. hydro), etc.

discharging static electricity on your body, etc.

- Do not disassemble of detach during operation

2 Model Number Configuration

3-point Hole Type Mounting • Terminal block (SL15 only)
(No text)
• KT only(SL15: No Buzzer)
Model Number Example S508 M1KTR B
- ∅80 - 12 - 24 V DC - 2-point hole type mounting • Terminal block
17 6

■ SK Model

Model Number Example
SKH-M1JB-R
- ∅100 - 12 - 24 V DC - Cabtve Cable - With buzze - Red color
5--7--8--6.

3 Part Names

■ Cable type □

Front view Terminal bl

Accessory List

	NameModel	QTY
SF□□-□□KT/SL□□-□□KT	Mounting Bracket, Waterproof Sheet	1
SF08-□□J/SL08-□□J/SKS Model	M4 Nut, Plain Washer	3
SF10-□□J/SL10-□□J/SKH Model	M5 Nut, Plain Washer	3
SL15-□□J/SKP Model	M8 Nut, Plain Washer	3

4 Installation

■ 3-Screw Mounting Type J T

(1) Insert the bolts of the beacon into

the holes of the mounting surface.

(2) Use the nuts and washer

(accessory) to secure in place.

Installation Example

Maximum Board Thickness of Mounti

Model	Maximum Board Thickness
SF08/SL08/SKS	9 mm
SF10/SL10/SKH	8 mm
SL15/SKP	10 mm

Installation Dimensions

Refer to the "Installation Manual"

[Non-Text]

■ 2-point Hole Type Mounting (SF • SL Models)

3-point Hole Type Mounting (SL15 Model Only)
(1) Use the screws or bolts, nuts. to secure the mounting bracket
(accessory) to the mounting surface.
(Installation screws and nuts are not included with this product. Binding head screws or pan head screws are recommended.)

Model	Screw Hole Depth of Mounting Bracket	Nominal Diameter
SF08/SL08	4.4 mm	M4
SF10/SL10	5.7 mm	M5
SL15	4.8 mm	M8

(2) Check that the O-ring is not twisted.

(3) Align the main unit of product with the positioning Indicator and turn it clockwise to lock it.

Installation Example

2-point Hole Type Mounting 3-point Hole Type Mounting

Installation Dimensions

Refer to the "Installation Manual"

NOTE TO THE INTERIOR MEETING

Caution Use a soft cloth moistened with water to clean the globe or sea. (Do not use thinner, hanging, gasoline or oil)

2001 (25 NO 200 Emitter, 2002), 2003 (25 No 200

Note The type with a buzzer, if the buzzer opening is splashed

with water, the Sound Pressure Level may drop.

5 Wiring

Caution • Make sure the power is OFF before wiring. A short circuit
■ Cation may damage internal circuits.
- Ensure damage
- Do not pull the wire, or stuff it inside of this case.
- Be sure the wiring is done properly. Any mistake in wiring may result in damage
- In the M2 model, do not perform blinking control by turning the power supply ON/OFF. Any mistake in wiring may result in damage.
- Do not apply a voltage to the common wire. (M1 type)
Do not apply a voltage to any wire other than the power supply wire. (M2 type)
Failure to comply will result in product damage.(except buzzer wire of SKH-M1) Do not exceed the wiring from the device. If tension is applied to the wiring, the
- DO NOT EXPOSE THE WING from the device. If tension is applied to the WING, the wiring may be disconnected, resulting in a short circuit or an electric shock.
- Use either a Contact Switch or Contact Relay for External Contact that power
supply wire of SF, SL, SK Models and buzzer wire of SK Model. Failure comply

may result in fire, product malfunction.

Notice The protection rating does not include the Cabtyre Cable

Ends.

If the ends of the it are in contact with water or exposed to dew or

condensation, refer to the indications below to dress the wire ends for water resistance.

resistanc Connect

- Connect the it ends in a location which will not expose the ends to water. - Use Fillers, such as silicen, etc., to seal the it ends.

[ External contact capacity of power supply wire ]

M1 M2

Current Capacity (in) 2A current 4A current

3A or more TA or more
[ External contact capacity of signal wire and buzzer wire ]
SF·SL Models

	M1	M2
Current Capacity (Is)	10 mA or more	10 mA or more
Withstand Voltage (Vs)	20 V or more	20 V or more
Leakage Current * (IL)	0.1 mA or less	0.1 mA or less

- When using an NPN open-collector transistor.

SK Model

M1	M2
0.5 A or more	0.5 A or more
35 V or more	20 V or more

[ Fuse ]

Fuse Rating 250 V 1 A

Wire Type / Wire Gauge

Wire Type : UL2464

Wire Gauge : M1 AWG22

□

M2 Power Supply Wire AWG18 Excluding Power Supply Wire AWG24

Wiring Example

Refer to the "Installation Manual".

Terminal Block Wiring

6 Specifications

• EMC Directive (EN61000-6-4, EN61000-6-2)

• RoHS Directive (EN50581

- UL908, CSA-C22.2 No.14 (File No. E215660) - ECC Part 15 Subpart B Class A

2.16.4 Part 10 Subpart B Class IV

This product conforms to EN standards and shows the CE Marking. This product has been tested and found to comply with the limits for a Close A

This product has been tested and found to comply with the limits for a Class A device, pursuant to EMC DIRECTIVE. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in

a commercial environment. This product must not be used in residential areas.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. The equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operations of this equipment in an antisidential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

[Non-Text]

(Note) • Dimensions and specifications may change without notice due to

continual product improvement

- PATLITE and the PATLITE logo is a trademark, or registered trademark of the PATLITE Corporation of Japan and each country.

the PATENTE Corporation of Japan and each country.

(Importer for EU)

PATLITE Europe GmbH Am Soeldnermoos 8, D-85399 Hallbergmoos, Germany
