ScreenCast AV 4 - Audio/video extender BELKIN - Free user manual and instructions
Find the device manual for free ScreenCast AV 4 BELKIN in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Type | Audio/Video Extender (Wireless HDMI Transmitter and Receiver) |
| Brand | Belkin |
| Model | ScreenCast AV 4 |
| Technology | Wireless (Proprietary RF) |
| Video Resolution | Up to 1080p |
| Audio Support | Stereo audio via HDMI |
| Transmission Range | Up to 30 meters (open space) |
| Latency | Approximately 200 ms |
| HDMI Ports | HDMI input (transmitter), HDMI output (receiver) |
| Power Supply | USB powered (5V/1A) |
| Dimensions (each unit) | 120 x 80 x 25 mm |
| Weight (total) | 200 g |
| Material | Plastic |
| Compatibility | HDMI devices (TVs, projectors, computers) |
| Setup | Plug and play, no drivers needed |
| Channels | Multiple channels to avoid interference |
| Security | 128-bit encryption |
| Included Accessories | Transmitter, receiver, HDMI cables, USB power cables, manual |
| Maintenance | Clean with dry cloth |
| Safety | Avoid moisture, keep away from heat sources |
| Repairability | Not user-serviceable; contact Belkin support |
Frequently Asked Questions - ScreenCast AV 4 BELKIN
How do I set up the Belkin ScreenCast AV 4?
Connect the transmitter to your source via HDMI and power via USB. Connect the receiver to your display via HDMI and power. They will automatically pair. If not, press the pairing button on both units.
What is the wireless range of the ScreenCast AV 4?
The range is up to 30 meters (98 feet) in open space. Walls and obstructions may reduce the effective range.
Does the ScreenCast AV 4 support 4K video?
No, it supports video resolutions up to 1080p (Full HD). It does not support 4K.
Can I connect multiple receivers to one transmitter?
Yes, you can connect up to 4 receivers to a single transmitter for multi-room viewing, depending on the model. Check the manual for exact limits.
Is the ScreenCast AV 4 compatible with my computer?
Yes, as long as your computer has an HDMI output, it is compatible. No additional software is required.
How do I reset the ScreenCast AV 4?
Use a pin to press and hold the reset button on each device for about 10 seconds until the LED blinks rapidly. This restores factory settings.
What cables are included in the box?
The package includes HDMI cables and USB power cables for both the transmitter and receiver. You may need to provide your own HDMI cables for longer distances.
Can I use the ScreenCast AV 4 to transmit audio only?
It is designed for both audio and video over HDMI. For audio-only, you would need a separate device. It does not have analog audio outputs.
Why is the connection dropping or unstable?
Check for interference from other wireless devices (Wi-Fi routers, microwaves). Try moving the transmitter and receiver closer, or change the wireless channel using the dip switches (if available).
Is the ScreenCast AV 4 wall-mountable?
No, it is not designed for wall mounting. Place it on a flat surface and ensure adequate ventilation.
