ScreenCast TV - Receiver BELKIN - Free user manual and instructions
Find the device manual for free ScreenCast TV BELKIN in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Type de produit | Receiver for screen mirroring |
| Brand | Belkin |
| Model | ScreenCast TV |
| Audio Output | HDMI (supports audio pass-through) |
| Video Output Resolution | Up to 1080p@60Hz |
| Wireless Connectivity | Wi-Fi 802.11 b/g/n, 2.4 GHz |
| Wireless Standards | Miracast, AirPlay, DLNA |
| Compatible Devices | iOS, Android, Windows, Mac |
| Power Supply | Micro USB, 5V/1A (adapter included) |
| Dimensions (L x W x H) | 2.8 x 2.8 x 0.7 inches (71 x 71 x 18 mm) |
| Weight | 1.6 oz (45 g) |
| Package Contents | ScreenCast TV receiver, HDMI cable, USB power cable, power adapter, quick start guide |
| Security Features | WPA2-PSK wireless encryption |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| Humidity Range | 10% to 85% (non-condensing) |
| Warranty | 1 year limited |
| Cleaning Instructions | Wipe with a dry, soft cloth. Do not use liquids or aerosols. |
| Repairability | No user-serviceable parts. Contact Belkin support for repairs. |
Frequently Asked Questions - ScreenCast TV BELKIN
How do I set up the Belkin ScreenCast TV receiver?
Connect the receiver to your TV via HDMI and power it with the included USB cable and adapter. Then, switch your TV to the corresponding HDMI input. Use your mobile device to connect to the receiver's Wi-Fi or use screen mirroring features like AirPlay or Miracast.
What devices are compatible with ScreenCast TV?
ScreenCast TV supports AirPlay for Apple devices (iPhone, iPad, Mac), Miracast for Android and Windows, and DLNA for media streaming. It works with most smartphones, tablets, and laptops.
Can I stream video from Netflix or other streaming apps?
Yes, you can mirror your device's screen, which includes streaming apps. However, note that some apps may block screen mirroring due to copyright restrictions. Using the app's built-in cast feature (if available) is recommended.
What should I do if the connection is unstable or laggy?
Ensure your mobile device and the receiver are on the same Wi-Fi network (if using that mode) and close to each other. Reduce interference from other wireless devices. For best performance, use a 5 GHz Wi-Fi router if supported, though this model uses 2.4 GHz.
How do I reset the ScreenCast TV to factory settings?
To reset, locate the reset button on the receiver (usually a pinhole). Use a paperclip to press and hold it for about 10 seconds until the LED flashes. The device will restart and clear all settings.
Can I use ScreenCast TV without an internet connection?
Yes, for Miracast connections, no internet is needed as it uses a direct Wi-Fi link between devices. For AirPlay and DLNA, a local network (router) is usually required, but internet access is not mandatory for mirroring.
What is the maximum range for wireless streaming?
The effective range is typically up to 30 feet (10 meters) in open space. Walls and obstacles can reduce range. For best performance, keep the receiver and your device within the same room.
Does the ScreenCast TV support 4K resolution?
No, this model supports up to 1080p Full HD at 60 Hz. For 4K streaming, consider a newer Belkin model or other devices.
How do I update the firmware on the receiver?
Firmware updates are typically applied automatically when the receiver is connected to the internet. You can also check for updates via the ScreenCast app (if available) or by visiting Belkin's support website for manual update instructions.
What should I do if the receiver does not power on?
First, ensure the power adapter is plugged in securely and the USB cable is connected. Try a different USB port or power source. If the LED does not light up, the unit may be defective; contact Belkin support for a replacement.
