| Product Type | Gas Tilting Kettle |
| Brand | Blodgett |
| Model | BLCM-61G |
| Capacity | 60 Gallons (227 Liters) |
| Power Source | Natural Gas or Propane |
| BTU Rating | 120,000 BTU/hr |
| Temperature Range | 150°F - 290°F (65°C - 143°C) |
| Material | Stainless Steel Exterior and Interior |
| Dimensions (W x D x H) | 36 x 36 x 36 inches (91 x 91 x 91 cm) |
| Net Weight | 500 lbs (227 kg) |
| Drain Valve | 3/4" Full Port Ball Valve with Lever Handle |
| Tilting Mechanism | Handwheel with Worm Gear, 90° Tilt |
| Thermostat | Adjustable Thermostat with Pilot Light |
| Safety Features | Automatic Gas Shut-off, High Temperature Limit, Pilot Safety Valve |
| Cleaning | CIP (Clean-in-Place) System with Spray Ball |
| Installation | Requires 6" Clearance from Combustible Walls, Adequate Ventilation |
| Warranty | 1 Year Parts and Labor, 5 Year on Kettle Body |
| Certifications | NSF, UL, CSA |
Frequently Asked Questions - BLCM-61G Blodgett
What type of gas does the Blodgett BLCM-61G require?
The BLCM-61G can operate on natural gas or propane. An orifice change is required for propane conversion.
How do I clean the kettle?
Use the integrated CIP (Clean-in-Place) system with a spray ball. Fill with water and detergent, heat to 180°F, circulate for 15 minutes, then rinse thoroughly.
What is the maximum temperature?
The adjustable thermostat allows a maximum temperature of 290°F (143°C).
How do I drain the kettle?
Open the full port ball valve located at the bottom. Use the lever handle for full flow drainage.
What safety features does it have?
It includes an automatic gas shut-off on flame failure, a high-temperature limit switch, and a pilot safety valve to prevent gas flow without a flame.
Can I replace parts if they break?
Yes, Blodgett offers replacement parts such as thermostats, drain valves, and gaskets. Contact authorized service centers.
What clearance is needed around the kettle?
Maintain at least 6 inches clearance from combustible walls and adequate ventilation per local codes.
How do I tilt the kettle?
Turn the handwheel clockwise to tilt forward. The worm gear mechanism allows up to 90° tilt for easy pouring.
What is the warranty?
Blodgett provides 1 year parts and labor, plus 5 years on the kettle body against defects.
Does it require electrical connection?
No electrical connection is needed for the gas models. The thermostat and pilot are self-generating or battery-powered. Check manual for specific ignition system.
