Cisco RV110W Wireless-N VPN Firewall
Simple, Secure Connectivity for the Small Office/Home Office
Connecting your employees to each other and your business to the world is an absolute requirement in today's always-on environment. Every business, even a small business, needs at least basic business-class connectivity—a combination of performance, security, and features that helps keep employees productive and your business assets safe.
The Cisco® RV110W Wireless-N VPN Firewall combines simple, highly secure wired and wireless connectivity for small offices and remote workers with a high-speed, 802.11n wireless access point, a 4-port 10/100 Mbps Fast Ethernet switch, an intuitive, browser-based device manager, and support for the Cisco FindIT Network Discovery Utility, all at a very affordable price. Its combination of business-class features, support for virtual networks to enable highly secure guest access, simple installation, and top-quality user experience takes basic connectivity for a small business with five or fewer employees to a new level.
With the Cisco RV110W Wireless-N VPN Firewall, you get:
High-speed wireless networking: The Cisco RV110W includes a built-in high-speed 802.11n wireless access point, supporting the latest Wi-Fi standards, to deliver a better experience for data, voice, and even video over your wireless network. Support for
Wi-Fi Protected Access (WPA2) helps keep your business safe from wireless attacks.
Highly secure remote access: Support for IP Security (IPsec) VPN connections enables you to securely connect up to five employees working remotely to your business network. A proven stateful packet inspection (SPI) firewall with support for access rules is a first line of defense that helps protect business assets.
Separate virtual networks: Intelligence built into the Cisco RV110W enables you to divide your wireless or wired network into four separate virtual networks to control access to sensitive information. You can also offer highly secure wireless guest access to your customers and partners and allow them to access the Internet without exposing your files.
Ease of use: A simple, intuitive, browser-based device manager makes the Cisco RV110W easy to set up and use. Support for Cisco FindIT offers even more insight into the Cisco Small Business devices in your network.
For More Information
To find out more about the Cisco RV110W and other Cisco Small Business solutions, visit www.cisco.com/go/smallbusiness.
The Cisco RV110W Wireless-N VPN Firewall includes:
| WAN and Network Edge | |
| 10/100 Mbps Fast Ethernet 1 port | |
| Network edge (DMZ) Software based | |
| LAN | |
| 10/100 Mbps Fast Ethernet 4-port switch | |
| VLAN support Yes | |
| Wireless | |
| High-speed 802.11n Yes | |
| 802.11b/g compatibility Yes | |
| Active WLAN client up to 32 clients | |
| Routing and Network | |
| IP and MAC filtering Yes | |
| Port forwarding and triggering Yes | |
| IPv6 Yes | |
| Routing Information Protocol (RIP) v1 and v2 Yes/Yes | |
| Inter-VLAN routing Yes | |
| Quality of service (QoS) Yes | |
| Security and VPN | |
| SPI firewall Yes | |
| Triple Data Encryption Standard (3DES) Yes | |
| Cisco Quick VPN/PPTP | 5/5 |
| Content/URL filtering | Yes |
| Management | |
| Browser-based configuration (HTTP/HTTPS) | Yes |
| Simple Network Management Protocol (SNMP) v3 | Yes |
Services and Support:
This Cisco Small Business product comes with a limited lifetime hardware warranty with return to factory replacement and a 1-year limited warranty for fans and/or power supplies. In addition, Cisco offers telephone technical support at no charge for the first 12 months following the date of purchase and software bug fixes, as available, for the warranty term. Product warranty terms and other information applicable to Cisco products are available at www.cisco.com/go/warranty.
Cisco Small Business products are supported by professionals in Cisco Small Business Support Center locations worldwide who are specifically trained to understand your needs. The Cisco Small Business Support Community, an online forum, enables you to collaborate with your peers and reach Cisco technical experts for support information.
The optional Cisco Small Business Support Service offers affordable, 3-year peace-of-mind coverage. This subscription-based, device-level service helps you protect your investment and derive maximum value from Cisco Small Business products. Delivered by Cisco and backed by your trusted partner, this comprehensive service includes software updates, extended access to the Cisco Small Business Support Center, and expedited hardware replacement, should it be required.
