BRUGSANVISNING CDX-FW560 SONY

XM Satellite Radio Receiver

Operating Instructions

Owner's Record

The model number is located on the bottom and serial number also on the bottom.

Second the serial number in the space provide below. Refer to these numbers whenever you call when your Sony dealer regarding this product.

Model No. XI-151

Serial No.

XT-XM1

Sony Corporation © 2002 Printed in Japan

WARNING

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part I5 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment oil and oil, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

— Container the equipment into an barrel or a circuit different from first to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

If you have any questions or problem reverbering (this product, result: your nearest Sony dealer.

If you have any questions or problem concerning the XM Satellite radio service including the produced version XM.

The XM Radio ID (XM-ID) is required when consulting XM. It is located on the bottom of the main unit, and you can also check it in the display of this unit (see "Displaying the XM Radio ID").

Welcome!

Thank you for purchasing the Sony XM Satellite Radio Receiver. The receiver allows you to

•Receive XM Satellite Radio programming (with

subscription) by connecting a Sony master unit compatible with the Sony BIOSystem.

• Connect and use an optional CD or MD

changer.

•Receive up to 100 channels of XM

programming.

• Display channel name, artist name, and song title for most XM channels.

• Store up to 20 favorite XM channels

• Search XM channels by category.

Some master units may not be connected to this receiver. (For details, please consult your nearest Sany dealer.)

Introducing XM™ Satellite Radio

There's a world beyond AM and FM, XM Satellite Radio. Up to 100 channels. Coast to Coast Coverage. Digital quality sound. With many commercial-free music channels. Plus, the best sports, comedy, talk, news and entertainment, including USA Today, Discovery Radio, NASCAR, Sesame Workshop, CNNfn and CNN/SL Questions? Visit

www.xmiradio.com. The future is waiting.

How to Subscribe

Listeners can subscribe by visiting XM on the Web at www.xmradio.com or by calling XM's Listcrer-Cancel [phone]. Customers should have their Radio ID reader; it is located or the bottom of the main unit, and you can also check it in the display of this unit (see "Displaying the XM Radio ID").

Technology. It is prohibited to try, discompile, disassemble, reverse engineer or manipulate any technology incorporated in receivers compatible with the XM Satellite Radio system.

Furthermore, the AMED® voice compression software included in this product is protected by intellectual property rights including patent rights, copyrights, and trade secrets of Digital Voice Systems, Inc. The user of this or any other software contained in an XM Radio is explicitly prohibited from attempting to copy, decompile, reverse engineer, or disassurable the object code, or in any other way convert the object code into human-readable form. The software is licensed solely for use within this product.

Getting Started

Resetting the master unit

Before operating the XM receiver for the first time, reset the master unit. If the unit is not reset in this manner, it may not function properly. For details on how to reset it, refer to the operating instructions of the master unit.

Caution

For the following master units, press the Repeal (KEP) button of the master unit for two seconds after turning the XM on and select "setup 2." Without this procedure, the master unit will not display tuning in information from the receiver correctly. Except for the following master units, "setup 1" is selected in the factory settings.

CDX-C8050X

CDX-C80OREC®

CDX-M750

CDX-M650 CDX-M610

CDX-M600

MDX-C8500X YP-M650

* You may observe flickering in parts of the display while performing operations. This is not malfunction.

Move

Reselling the master unit will create the clock sorting and some stored contents of the master unit.

Basic Operations

Listening to a program

The XM receiver is controlled by the master unit button locations vary with different master unit models. Please refer to the master unit instruction manuals.

1 To select XM:

a. Press the Sunday bullet on until "XM" is displayed.

b. Press the Source button until "MD" is displayed, then press the Mode button to select XM. For master units which can central move than one MD changer, press the Mode button repeatedly (the display will show "MD1," "MD2," etc.) until the receiver is found.

2 Press either Seek button to select the desired channel.

Pressing and holding the Sack button will quickly step through the channels

Note "LOADING" is indicated while the receiver is reading the information.

Display items

The XM Satellite Radio information (Channel Name, Channel Number, Artist Name/Program Name and Song Title) is available on the display.

Press the Display (DSPL) button. Each time you press the Display (DSPL) button, the item changes so follows: Channel Name → Channel Number → Artist Name/Program Name → Song Title → For MEX 5DI, press the ENTER button of the remote control to change the display item.

Notes

- White Star Name/Program Name or Song Title is displayed, if you select a channel, Channel Name will be displayed for 2 to 3 seconds and then return to the previous display.

• If there is no information about Active Name Program Name or Song Title, will be displayed.

- During XM Satellite field reception, Spectrum Analyzer. Dual Information, Horizon Display function of the master unit cannot be operated - The display indicates up to 8 characters. The characters on the display cannot be secreted even when the Active Scroll function of the master unit is set to on.

- You cannot display the clock during XMI Satellite Radio reception on a meter unit whose clock display is shown by pressing the Display (DSPL) button.

Using category search to locate channels

Each XM channel is associated with a category that describes the type of music or programming that is played on the channel. Examples of categories include "rock," "jazz," "news," and so on. Users are familiar with XM's programming may use the radio's search-by-category function to select channels.

1 Press the Repeat (REP) button to enter category search mode. The category of the current channel is dipleted. Will some master units, the Repeat button is only equipped on the remote control.

2 Press the Disc Preset buttons repeatedly until you find the desired category.

3 Press the Seek buttons repeatedly until you find the desired channel in that category. The display shows "CAT SRCH" to indicate that the radio is in category search mode. While in this mode, you will only be able to turn to channels in the selected category. You may use the Disc/Preset buttons to choose other categories.

4 To exit from category search mode and return to the normal mode, press the Repeat (REP) button. The radio automatically returns to the normal mode if there no key is pressed within 5 seconds.

Storing favorite channels

You can preset up to 20 channels.

1 Tune in a channel that you want to store.

2 Press the Shuffle (SHUF) button. The radio will show a list of presets, starting with preset number 1. The preset number will be shown if a channel has already been stored into the preset. With some master units, the Shuffle button is only equipped on the remote control.

3 Press the Disc/Preset button to select a preset number. With some master units, the Disc/Preset button is only equipped on the remote unit.

4 Press the Disc Preset + (Disc +) button for 2 seconds. The display shows "MEMORY" if the radio successfully stores the channel into the preset. The display shows "FALLKE" if the radio fails to store the channel into the preset. The radio automatically returns to the normal mode if there no key is pressed within 5 seconds.

Receiving a stored channel

- Press either Disc/Preset button to select the preset channel you want to listen to. - Press the Shuffle (SHUF) button. Press the Disc/Preset + (DISC+) button to select the preset channel and then press the SEEK + or SEEK - button to start.

Displaying the XM Radio ID

1 During XM Satellite Radio reception, press the Seek button to select "CHANNEL 1."

2 Press the "Seek - (down)" button. "RADE ID" is indicated for 2 seconds and the XM Radio ID number is indicated for 10 seconds. These indications will be displayed alternately.

To cancel the NM Kadiu 12 display, press the Sisk button to select a channel.

Additional Information

Specifications

Ектурина 2352.5-2345.0 MHz

Power requirements 12 V DC car battery

(Negative ground)

Auction output

Inputs Antenna input (Satellite,

Terres(rial) BUS control input Audia input Dimensions 224 - 37.8 - 160 mm (8 - /s - 1 /s - 6 - /s in.) (w/l/d)

Miss Approx. 10 kg

Supplied accessories. Parts for installation and

reaction (1 sc)

Design and specifications are subject to change without notice.

Troubleshooting

Should any problem persist after you have made the following checks, consult your nearest Sony dealer. Consult XM if you have any questions or problem concerning the broadcast service of the XM Satellite radio.

The information on the display cannot be

changed during XM Satellite Radio reception.

- K_H is a calculated result.

• Adjust the volume control of the master unit.

- Cancel the alternate function of the master

unit.

• The connecting cards are not connected properly.

The sound is hampered by noises.

I male corks and cables such as an antenna code, a BUS cable, an RCA pin code, or a power code so as they do not interfere each other.

The channels cannot be received. Check the connection of the receiver and the antenna.

Advisory Message

When a problem occurs with the receiver, an error message will be indicated on the display of the master unit.

ANTENNA

The antenna is not connected properly. → Check the connection of the receiver and the antenna.

UPDATING You have not subscribed to XM, or the channel is not authorized. * We need to subscribe to XM.

NO SIGNI

XM signal is too weak. → Move to another area where your system can receive the signal.

The channel is not broadcasted now.

→ Select another channel

LOADING

The receiver is reading the channel information.
→ Wait until the receiver completes receiving the information.

"----" or "CH ----" • The channel to be tuned in is void due to the change by the broadcast service, or the receiving condition is not good. • There is no text information or time information in the channel. This is not an error.

Installation

Parts list

The numbers in the list are keyed to those in the instructions.

① ② ③ ④ ø4 : 14 mm 4 5.0m 5.5m 5.5m

Precautions

• Choose the mounting location carefully, observing the following:

The unit is not subject to temperatures exceeding 55°C (131°F) such as in a car parked in direct

sunlight).

— The unit is not subject to direct sunlight.

— The unit is not near heat sources (such as heaters).

— The unit is not exposed in rain or moisture.

— The unit is not exposed to excessive dust or dark

— The unit is not subject to excessive vibration.

— The half tank should not be labeled by the lapping screws.

— There should be no white harnesses of pipes under the place where you are going to mail the

,init.

— The spare fire, fools or other equipment in or under the trunk should not be interfered with or

damaged by the screws of the tum itself.

*Be sure to use only the supplied mounting hardware for a safe and secure installation.

• Use only the supplied traces.

Installing the unit

- Mount the unit either inside the trunk or under a seal.

• Choose the mounting location carefully so the unit will not interfere with the normal movements of

the driver and it will not be exposed to direct sunlight or hot air from the heater.

- Do not install the unit under the floor carpet, where the heat dissipation from the unit will be

considerably impaired.

First, place the unit where you plan to install it, and mark the positions of the time screw holes on the mounting surface.

Screw hole: ø3.3 mm (F/ø in.)

Notes

• Use only the supplied screws.

- Be sure not to damage the fuel rank or brake line with the footing screws.

Fuse replacement

If the fuse blows, check the power connection and replace the fuse. If the fuse blows again after replacement, there may be an internal malfunction.

Warning

Use a fuse with the specified amperage rating.

Use of a higher amperage fuse may cause serious damage

Connection

Connection example

Cautions

- This unit is designed for negative ground 12 V DC operation only.

- Before making connections, turn the car ignition off to avoid short circuits.

- Connect the yellow power input card only after all other cards have been connected.

- Run all ground leads to a common ground point.

Connection diagram
