NAUDOJIMO INSTRUKCIJA CH 7000 TURBO Fantini Cosmi
FAN HEATER
CH 7000CH 7000 TURBOTURBO SERIES
indoor applications
floor and wall mounting
DESCRIPTION:
Electric heaters with an innovative design in the family of convector heaters, stand out for their tapered and extremely compact line.
They are equipped with an adjustable thermostat that permits to pre-set the room temperature at the desired level
The TURBO version with its powerful and noiseless centrifugal fan allows quick and efficient heat diffusion in the room.
Moreover, the three levels of power allow to manage properly the energy saving, without sacrificing performance and high comfort level.
IP20
230V
CE
MAIN FEATURES:
■ Bivalent products suitable for floor and wall installation through a special support system.
■ With daily mechanical programmer.
■ Safety thermal device.
■ 3 power rates:
750W - 1250W - 2000W.
■ 150 cm cable with Schuko plug.
DIMENSIONS
| MODEL depth width height | mm | ||
| CH 7000 TURBO 105 580 377 | |||
| CH 7000 TURBO TIMER 105 580 377 | |||
TECHNICAL SPECIFICATIONS
STANDARD
| CODE | MODEL | V | Hz | W | max | Kg | |||
| AP6576 | CH 7000 TURBO | 230~50 | 2000 | 3,2 | |||||
WITH DAILY MECHANICAL PROGRAMMER
| CODE | MODEL | V | Hz | W | max | Kg | |||
| AP6578 | CH 7000 TURBO TIMER | 230~50 | 2000 3,2 | ||||||
