KASUTUSJUHEND TeraStation 7120 BUFFALO
Key Features
- Intel® Xeon® quad core processor
• 12-bay 2U rackmountable (12-96 TB) - Partially or fully-populated with hard drives
• Quad Intel NICs + 10GbE NIC support - Redundant hot plug PSUs and fans
• Hot-swap & Hot spare hard drives
• RAID 0/1/5/6/10/51/61/JBOD
• Cloud storage backup to Amazon S3
• Real-time replication to other TeraStation NAS devices
• Simultaneous NAS and iSCSI target functionality
• Active Directory support
• DFS Namespace support - VMware® Certified, Citrix® Ready and compatible with Hyper-V®
• Sliding rail kit included (4-post) - NovaBACKUP® Buffalo Edition included (1 server and 10 workstation licenses)
• Optional 5-year enhanced warranty
Enterprise-Class Network & iSCSI Storage
Featuring the powerful Intel Xeon quad-core processor and either standard or enterprise hard drives, the TeraStation 7000 series provides exceptional performance during file transfers and everyday NAS functions.
The TeraStation 7120 and 7120 Enterprise rackmount solutions come equipped with enterprise-class features such as Active Directory support, disk quota support, share level replication, hot-swap hard drives and iSCSI targeting. Other key features include quad gigabit Ethernet ports supporting link aggregation to 4 Gbps and PCI-Express expansion with 10GbE NIC support (see specs for qualified models).
PRODUCT SPECIFICATIONS
| MODELS | TS-2RZSD (TeraStation 7120) | TS-2RZHD (TeraStation 7120 Enterprise) |
| Part Numbers | TS-2RZS12T04D (12 TB) | TS-2RZH24T12D (24 TB)TS-2RZH48T12D (48 TB)TS-2RZH72T12D (72 TB)TS-2RZH96T12D (96 TB) |
| Configuration | Rackmount | Rackmount |
| INTERNAL HARD DRIVES | ||
| Number of Bays | 12 x 3.5" HDD | 12 x 3.5" HDD |
| Number of Drives | 4 | 12 |
| Hard Drive Capacities | 3 TB | 2, 4, 6, 8 TB |
| Total Capacity | 12 TB | 24, 48, 72, 96 TB |
| Drive Interface | SATA II/III 3 Gbps | SATA II/III 3 Gbps |
| Supported RAID | 0/1/5/6/10//51/61/JBOD (Individual Disks) | 0/1/5/6/10/51/61/JBOD (Individual Disks) |
| USB INTERFACE | ||
| Standards Compliance | USB 2.0 | USB 2.0 |
| Number of Ports | 6 Type A | 6 Type A |
| Data Transfer Rates | 480 Mbps (USB 2.0) | 480 Mbps (USB 2.0) |
| Expansion Slots | PCI-Express x8 slot x 1, PCI-Express x4 slot x 1 | PCI-Express x8 slot x 1, PCI-Express x4 slot x 1 |
| PERFORMANCE | ||
| CPU | Intel® Xeon® Processor E3-1225 (3.10 GHz quad-core) | Intel® Xeon® Processor E3-1275 (3.40 GHz quad-core) |
| Memory | 4 GB DDR3 RAM (Scalable to 16 GB) | 8 GB DDR3 RAM (Scalable to 16 GB) |
| ENVIRONMENTAL & POWER | ||
| Power Consumption | Max 250W | Max 250W |
| Power Supply | Internal AC 100-240V Universal, 50/60Hz | Internal AC 100-240V Universal, 50/60Hz |
| Operating Temperature | 41° - 104°F (5° - 40°C) | 41° - 104°F (5° - 40°C) |
| Operating Humidity | 20 - 80% non-condensing | 20 - 80% non-condensing |
| SHIPPING | ||
| Dimensions (L x W x H) | 29 x 18.9 x 3.46in | 29 x 18.9 x 3.46 in |
| Weight | 43 lbs | 60.4 lbs |
LAN INTERFACE
| Standards Compliance | IEEE802.3, IEEE802.3u, IEEE802.3ab |
| Number of Ports | 4 |
| Data Transfer Rates | 10 / 100 / 1000 Mbps (Auto Sensing) |
| Supported Protocols | TCP/IP |
| File Sharing | CIFS/SMB, AFP, HTTP/HTTPS, FTP/SFTP/FTPS, NFS |
| Connector Type | RJ-45 |
| CLIENT OS SUPPORT | Windows® 10, Windows® 8.1 (32-bit/64-bit), Windows® 8 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows® 7 Professional (64-bit), Windows Vista® (32-bit/64-bit), Windows® XP, Windows® 2000, Windows Server® 2012, Windows Server® 2012 R2, Windows Server® 2008, Windows Server® 2008 R2, Windows Server® 2003, Windows® 2000 Server, Mac OS® X up to 10.10 |
ACCESSORIES
| Replacement Hard Drives | TeraStation 7120: OP-HD3.0ZS-3YTeraStation 7120 Enterprise: OP-HD2.0ZH-3Y, OP-HD3.0ZH-3Y, OP-HD4.0ZH-3Y, OP-HD6.0ZH-3Y, OP-HD8.0ZH-3Y |
| Replacement Fan | OP-FAN-2RZ |
| Replacement Power Supply | OP-PU-2RZ-3Y |
| Memory Upgrades | OP-MEM-4GX2-3Y, OP-MEM-8GX2-3Y |
| PCI Express Card | IFC-PCIE2U3S2 |
| Compatible 10 GbE NICs | Emulex: OCe11102-N, OCe11102-I, OCe11102-FIntel: X540T2, E10G42BtDA, E10G41BFSR, E10G42BFSR, E10G41AT2 |
| BOX CONTENTS | TeraStationTM, Setup CD-ROM, Ethernet Cable, AC Cable (2), 4-Post Rackmount Rails, Quick Setup Guide, Warranty Statement |
| INCLUDED SOFTWARE | NASNavigator, NovaBACKUP® Buffalo Edition (one server and ten workstation licenses) |
