KASUTUSJUHEND Power Star 13.2 MAC AUDIO
POWER STAR 2.16 POWER STAR 2.13
• Solid steel basket including additional voice-coil ventilation
• Polypropylene cone with titanium hairline finish
- Long excursion rubber surround
• Titanium-coated tweeter/midrange cone (69.3)
• Mac Audio design magnet protection cover
- Suspension and magnetic field optimised with KLIPPE ^® lmeasurement system
• Solid hexagon protection cover with aluminium diamond-cut logo
• Titanium tweeter (2.16/2.13)/Titanium-coated tweeter cone
• External XO including PTC tweeter protection circuit (2.16/2.13)
| SPECIFICATIONS | Power Star 2.16 | Power Star 2.13 | Power Star 69.3 | Power Star 16.2 | Power Star 13.2 | Power Star 10.2 |
| Principle 2-way 2-way 3-way 2-way 2-way 2-way | ||||||
| System compo compo triaxial coaxial coaxial coaxial | ||||||
| Power handling RMS/max. (W) | 100/400 80/320 120/480 | 100/400 80/320 | 60/240 | |||
| Impedance (Ω) | 4 | 4 | 4 | 4 | 4 | 4 |
| Frequency response (Hz) | 30 - 26 000 | 34 - 26 000 | 28 - 24 000 | 30 - 24 000 | 34 - 24 000 | 38 - 24 000 |
| Crossover frequencies (Hz) | 3 800 | 3 800 | 2 800/4 200 | 4 200 | 4 200 | 4 200 |
| SPL (dB) | 90 | 90 | 91 | 90 | 90 | 89 |
| DIN-∅ (mm) | 165 W/19 T | 130 W/19 T | 6x9" /0.5" /2" | 165 W/13 T | 130 W/13 T | 100 W/13 T |
| Cutting Out (mm) | 142 W/38 T | 113 W/38 T | 221 x 151 | 142 | 113 | 94 |
| Mounting depth (mm) | 57 W/ 17 T | 51 W/ 17 T | 78 | 57 | 51 | 50 |
| Art.No. | 110 5726 | 110 5723 | 110 5719 | 110 5716 | 110 5713 | 110 5710 |
| EAN. | 40 23037 05726 3 | 40 23037 05723 2 | 40 23037 05719 5 | 40 23037 05716 4 | 40 23037 05713 3 | 40 23037 05710 2 |
