Yvonne BA 1007 - Scale ADE - Free user manual and instructions

Product Type	Body Composition Scale
Brand	ADE
Model	Yvonne BA 1007
Dimensions (W x D x H)	Approx. 230 mm x 130 mm x 21 mm
Maximum Capacity	150 kg
Graduation	100 g
Weight Units	kg, lb, st:lb
Power Supply	1 CR2032 battery (included)
Main Functions	Weighing, body fat analysis, water mass, muscle mass, bone mass
Number of User Memories	10 (P0 to P9)
Age Range	10 to 80 years
Height Range	100 to 220 cm
Display	LCD screen with backlight
Power On	By contact (Tap-on) or ON/OFF switch
Auto Power Off	After about 15 seconds of inactivity
Platform Material	Tempered glass
Measurement Conditions	Barefoot, on a flat and hard surface
Safety	Do not use with a pacemaker or electronic implant
Care and Cleaning	Clean with a damp cloth; do not use solvents or immerse in water
Warranty	3 years (repair or replacement)
Batteries: safety instructions	Do not open, expose to fire or shocks; store below 40 °C
Recycling	Do not dispose of with household waste; return to collection point

Frequently Asked Questions - Yvonne BA 1007 ADE

How to turn on the ADE Yvonne BA 1007 scale?

You can turn on the scale in two ways: either by briefly pressing the platform with your foot (Tap-on function), or by using the ON/OFF switch located under the scale.

How to save my personal data (gender, height, age)?

After turning on the scale, touch a corner of the screen. Use the ▲ and ▼ buttons to select a memory location (P0 to P9), then press SET. Follow the steps to choose gender, height, and age, confirming each with SET.

Why does the scale display 'Err' or 'Err1'?

Err: weighing error, usually if you move during measurement or if the scale is not stable. Err1: overload, the maximum capacity of 150 kg is exceeded. Remove the load immediately.

What does 'Err2' mean?

Err2 indicates a body fat measurement error: the percentage is below 5% or above 75%. Make sure you are barefoot and still.

How to replace the scale's battery?

Open the battery compartment under the scale and replace the used battery with a new CR2032 battery, respecting polarity (+/-). If the scale displays 'Lo', the battery is empty.

Can I use this scale if I have a pacemaker?

No, the scale is not suitable for people with a pacemaker or any other electronic implant. The low electrical current used for analysis could interfere.

Why do measurement results vary during the day?

The body undergoes natural fluctuations (hydration, food intake). For comparable results, always weigh yourself at the same time, ideally in the morning 15 minutes after waking up, and under similar conditions.

How to clean the scale?

Use a soft damp cloth. Never use solvents, abrasive products, and do not immerse the scale in water.

What is the warranty of the ADE Yvonne BA 1007 scale?

ADE offers a 3-year warranty from the date of purchase against any manufacturing defects. To activate it, have your retailer fill out the warranty card.

How to change the weight unit (kg, lb, st)?

Under the scale, to the right of the ON/OFF switch, there is a small UNIT switch. Set it to the desired position: kg for kilograms, lb for pounds, st:lb for stones and pounds.

USER MANUAL Yvonne BA 1007 ADE

1. Lithium batteries are lithium manganese cells. If you do not use the scale over a longer period, you should take out the batteries of the device.
2. Never open the lithium battery, do not put into fire, or expose to shocks because an expi sion risk lasts or discharge of poisonous exposure to fumes might possible.
3. Never touch leaked cells with bare hands.
4. When eyes or hands are contaminated, it is essential to rinse with lots of water. You should go to a doctor if skin or eyes are irritated.
5. Dispos cells only completely discharged or protected against polarity reversal wrapped according to your local disposal regulation.
6. Do not expose the cells to direct solar radiation and store away from heat; otherwise, there is risk of overheating.
7. Maintain a storage temperature of < 40^ C .

Disposal of old electrical and electronic equipment

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead, it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. For more and detailed information about recycling contact your local city office, your household waste disposal service or the shop where you purchased the product.

With kind regards

ADE (GmbH & Co.)

Guarantee Card 3 years warranty for the Body Analysing S scale

Sender

Reason for complaint

Please return this guarantee card together with the receipt to your retailer.

8

Operating Manual BA1007_YHF1509SLBN150324REV00

BODY FAT

BODY WATER

MUSCLE MASS

BONE MASS

Model Yvonne / BA 1007 Instruction Manual

Directory

1. How does the body analyser work? Page 2
2. Conditions to use.. Page 2
3. Commissioning..
4. Programming / enter of personal data..
5. Body Analysis.. Page 5
6. Error Messages..
7. Technical Data
8. Warranty..

1

Thank you for your decision to purchase this high quality body analyser scale. Please peruse read this instruction manual prior to first start up and keep this user instruction careful so as to have this information on hand whenever it is needed.

1. How does the body analyser work?

Through this new revolutionary scale, you will be able to get information about your body composition with reference to your weight, body fat % ,body water % muscle mass % and bone mass kg. First of all, you have to enter once your personal data like gender (male or female), body height and age under your selected personal memory location. Afterwards a measurement is as simple as on a normal bathroom scale. You have only to select your personal memory location, step on the scale and within a few seconds, your measured values will be indicated. The analysis based on the measurement of the body's electrical resistance. A low, safe electrical signal passes freely through fluids contained in lean tissue, such as muscle and blood, but meets resistance passing through fat tissue. The body analyser accurately measures the resistance and with reference to your personal data use it to calculate elements of body composition.

2. How to use

If possible, the measurement should be done undressed but always barefoot.

By nature, a body is subject of fluctuations (for example, loss of water after taking exercise or after a sauna visit, after a meal, etc.). To enable comparable readings it is important to take the measurements as possible always under the same conditions.

In order to ensure that the results of analysis are accurate and consistent, please keep the measurement conditions constant always at the same daytime. In the morning, directly after you've woken up, your body will be dehydrated and also the majority of fluid will be stored in the central trunk area. This means that the resistance is relatively high because of the poor conductivity in the body. By intensify moving during the day progresses the fluid becomes more evenly distributed through the limbs and increasing the accuracy of the readings. To get a realistic result it is important to take your readings at the same time and under the same conditions every day. The easiest way to stick the rule, measure always in the morning, 15 minutes after you've got up, either before or after you've gone to the bathroom.

In spite of a very low electrical signal, this body analyser is not suitable for persons with heart pacemaker or other electronic medical implants! There is no risk for persons with none electronic implant for instance a titanium plate in the knee. However, metal conducts the electric current extremely well and therefore the scale implicates the body fat value beautified means the actual body fat value is higher as indicated. However, tendencies may be determined as well.

Due to menstrual cycle and hormonal changes women experience greater changes in their hydration level. Retaining fluid may cause the weight to fluctuate day-to-day. This

7. Technical Data

Capacity x graduation: max. 150 kg x 100 g

Display resolution: body fat: 0.1%

Display resolution: body water: 0.1%

Display resolution: muscle mass: 0.1%

Display resolution: bone mass: 100 g

Personal memory loc.: 10 positions

Age: 10 80 years

Body height: 100 220 cm

Dimensions: approx. 230 mm x 130 mm x 21 mm

Battery: 1 x CR2032 (included)

Subject to technical modifications

8. Warranty

ADE warrants for a period of 3 years from the date of purchase that it will remedy any defects due to faulty material or workmanship free of charge by repair or replacement. When purchasing, please have the warranty coupon signed and stamped by the dealer. When making a guarantee claim, please return the weighing scale together with the guarantee card including the reason of complaint to your dealer.

CE-Conformity. This device features radio interference suppression in compliance with valid EC Regulation 2004/108

Note: The displayed value may be adversely affected under extreme electromagnetic influences, e.g. when using a radio unit in the immediate vicinity of the device. Once the interference has been rectified, the product can once again be used for its intended purpose. The device may have to be switched-on again.

Statutory instructions on battery disposal

Batteries must not be disposed as household waste. The law requires that you, as consumer, return the waste batteries either to public collection points in your town or village or to any outlet selling batteries of the same kind.

Note:

Batteries are marked as follows:

Li Battery contains Lithium

AI = Battery contains Alkali

Mn = Battery contains Manganese

CR (Li); A (Al, Mn); AA (Al, Mn); AAA (Al, Mn)

The average total body water percentage range for healthy men is between 50 - 65%. The equivalent value for women is approximately 45 - 60% due to the higher body fat content. About two third of the total body water is stored in the coils and is therefore called intra cellular. The other third of the total body water is extra cellular body water.

Women
AGE	Body Fat	Body Water
slim	normal		sighly overweight	overweight	normal
10-16	<18%	18-28%	29-35%	>35%	57-67%
17-39	<20%	20-32%	33-38%	>38%	47-57%
40-55	<23%	23-35%	36-41%	>41%	42-52%
56-85	<24%	24-36%	37-42%	>42%	37-47%
Men
AGE	Body Fat				Body Water
	slim	normal	sighly overweight	overweight	normal
10-16	<10%	10-18%	19-23%	>23%	58-72%
17-39	<12%	12-20%	21-25%	>25%	53-67%
40-55	<13%	13-21%	22-26%	>26%	47-61%
56-85	<14%	14-22%	23-27%	>27%	42-56%

There are no validated standards for muscle mass.

6. Error Messages

Err1 Overload - The weight exceeds the maximum capacity of 150 kg. Please immediately remove the critical load to avoid load cell damage.

Err = Incorrect weighing process - For example, the scale is placed unstable or you do not remain stationary on the weighing platform.

Incorrect measuring process at body fat analysing If body fat is lower than 5% or higher than 75% .

Battery is used up Please replace the battery with the intended type (1 x CR2032).

will also affect the body fat percentage readings. If the hydration level is high, the body will also affect the body fat percentage readings. If the hydration level is high, the body fat percentage is slightly less a loss hydration level means the body fat percentage is slightly higher.

There is no healthy risk for pregnancy. The body analyzer is absolutely safe for the mother and her unborn baby. However, due to the changes in water content in the mother's body, the readings should not be interpreted as completely accurate.

ADE Germany takes no responsibility for any damages or losses caused by the use of this body analyzer scale or for Third Party claims. This product is exclusively intended for private use. This product is not designed for commercial or professional use in hospitals or other medical facilities.

3. Commissioning

Safety guidelines:

The appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless a person responsible for their safety has given them supervision or instruction concerning use of the appliance. Children should be supervised to ensure that they do not play with the appliance.

Not suitable for persons with electronic implants (heart pacemaker, etc.).

Place the scale on a plane and firm surface (tiles, hardwood flooring, etc.) to avoid a wrong measurement on carpeted floor

Attention - Hazard of slips! Do not stand on the scale with wet feet or on a slippery surface of the weighing platform.

Please care that no heavy object may fall on the scale. The glass surface is breakable.

Clean the scale only by using a slightly damp cloth. Do not use solvents or abrasive cleaning agents. Do not submerge the scale under water.

Preparation:

Open the battery cover at the bottom side of the scale and insert the supplied battery (1 x CR2032). Please ensure the correct polarity of the batteries (+/-).

Extract the display, which is located beneath the weighing platform. To switch-on / switch-off the scale you will find a little black ON/OFF-switch at the underside of the scale.

Automatic switch-on / switch-off the scale

If the scale is switched-on and the indicated value does not change within approx. fifteen seconds, the scale automatically switch-off. To switch-on the scale again it is sufficient to touch lightly a corner of the display.

Units of weight:

There is a little push button UNIT at the bottom of the scale on the right beside the ON/OFF-switch for country specific setting with the option to switch from kg = kilogram to lb = pound or to st; lb = stone pound. Please pay attention to use the scale under consideration of your country specific unit of weight.

4. Programming / Enter of personal data

Before first time use your personal data like gender (male or female), body height and age must be programmed and saved under selected locations P0 P9 (up to 10 persons). The scale is equipped with highly sensitive touch buttons. The touch buttons are located above the display. To enter your personal data please utilise the buttons: SET (on and save button), (plus button), (minus button) and follow the particular points:

1. Touch lightly a corner of the display. The display indicates flashing P0. To select your personal location (P0 P9), touch the or -button. After the selection of your personal location, touch the SET-button to save the reading.
2. After you we selected your personal location (e.g. P3), the symbol for gender starts to flash. To select the requested gender (▼ male or ▲ female), touch the ▲- or ▼-button. After the selection of your gender, touch the SET-button to save the reading.
3. After you've selected your gender (e.g., female), the symbol for body height (default 165 cm) starts to flash. To enter your body height, touch the or -button. After the selection of your body height, touch the SET-button to save the reading.
4. After you've selected your body height, the symbol for age (default age 25) starts to flash. To enter your age, touch the or button. After the selection of your age, touch the SET-button to save the reading.

After input completion, the display indicates --- and the scale returns to 0.0 kg.
Shortly after, the scale automatically powers off.

To enter personal data of further persons please repeat the steps listed below.

5. Body Analysis

An analysis is only possible in bare feet. Your personal data must be entered first (please see page 4).

1. Switch on the scale by using the Tap-on-function. For this, step short with your foot on the scale. First, the display indicates the personal data of the last allocation and a few seconds later 0.0kg . If they are not your personal data please select your personal memory location (where your personal data are stored) by using the or -key. Your personal data will indicate and then the scale returns to 0.0kg .
2. Now, carefully step in bare feet on the right and left stainless steel electrodes (measuring units) of the scale and remain stationary.

3. At first, your weight will indicate on the display. Shortly after, while the analysis is taking place, the signal o starts to move in the display. Still remain stationary on the scale. After completion of the measurement, your measured values will be shown as follows:

4. Your body fat in % and as subtitle an evaluation:
   (-) insufficient body fat - (0) healthy (+) too much body fat (++) obese

5. Your body fat in %
   3.Your muscle mass in %
6. Your bone mass in kg

After a few seconds the scale switch-off automatically.

The body fat content is shown as the amount of stored fat as a percentage of total body weight. There is no generally accepted set value as this varies significantly according to gender (due to the different build) and age. Body fat is vital for basic body functions. It's protecting organs, cushioning joints, regulating body temperature, storing vitamins and serves the body as energy storage.

As essential for women a minimum body fat proportion between 10% and 13% and for men between 10% and 13% is requested - with the exception of competitive athletes.

Body fat is not a clear indicator for health. Too high body weight and a too high body fat proportion are linked to the incidence of many civilization diseases such as diabetes, cardiovascular diseases, etc. Lack of movement and improper nutrition are often the prime course for these diseases. There is an obvious direct relationship between overweight and lack of movement.

A significant part of the human body consists of body water. This body water is differently distributed throughout the whole body. Lean muscle tissue contains approx. 75% body water, blood approx. 83% body water, body fat approx. 25% body water and bones have a water content of about 22% .

Femmes
Âgo	MasseGRAUSSUECORPOLE				Masse d'eau
	mince	normal	lager surpoids	surpoids	normal
10-15	<18%	18-28%	29-35%	>35%	57-67%
17-39	<20%	20-32%	33-38%	>38%	47-57%
40-55	<23%	23-35%	36-41%	>41%	42-52%
56-85	<24%	24-36%	37-42%	>42%	37-47%
Hommes
Âgo	MasseGRAUSSUECORPOLE				Masse d'eau
	mince	normal	lager surpoids	surpoids	normal
10-16	<10%	10-18%	19-23%	>23%	58-72%
17-39	<12%	12-20%	21-25%	>25%	53-67%
40-55	<13%	13-21%	22-26%	>26%	47-61%
56-85	<14%	14-22%	23-27%	>27%	42-56%

MUSCULAR
MASSA OSSEA

Indices

1. Lithium batteries are lithium manganese cells. If you do not use the scale over a longer period, you should take out the batteries of the device.
2. Never open the lithium battery, do not put into fire, or expose to shocks because an expid tion risk lasts or discharge of poisonous exposure to fumes might possible.
3. Never touch leaked cells with bare hands.
4. When eyes or hands are contaminated, it is essential to rinse with lots of water. You should go to a doctor if skin or eyes are irritated.
5. Dispos cells only completely discharged or protected against polarity reversal wrapped according to your local disposal regulation.
6. Do not expose the cells to direct solar radiation and store away from heat; otherwise, there is risk of overheating.
7. Maintain a storage temperature of < 40^ .

Disposal of old electrical and electronic equipment

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead, it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. For more and detailed information about recycling contact your local city office, your household waste disposal service or the shop where you purchased the product.

With kind regards

ADE (GmbH & Co.)

Guarantee Card 3 years warranty for the Body Analysing S scale

Sender

Reason for complaint

Please return this guarantee card together with the receipt to your refslier.

BODY FAT

BODY WATER

MUSCLE MASS

BONE MASS

Model Yvonne / BA 1008 Instruction Manual

Directory

1. How does the body analyser work? Page 2
2. Conditions to use.. Page 2
3. Commissioning.. Page 3
4. Programming / enter of personal data...
5. Body Analysis
6. Error Messages..
7. Technical Data..
8. Warranty..

Thank you for your decision to purchase this high quality body analyser scale. Please peruse read this instruction manual prior to first start up and keep this user instruction careful so as to have this information on hand whenever it is needed.

1. How does the body analyser work?

Through this new revolutionary scale, you will be able to get information about your body composition with reference to your weight, body fat % ,body water % muscle mass % and bone mass kg. First of all, you have to enter once your personal data like gender (male or female), body height and age under your selected personal memory location. Afterwards a measurement is as simple as on a normal bathroom scale. You have only to select your personal memory location, step on the scale and within a few seconds, your measured values will be indicated. The analysis based on the measurement of the body's electrical resistance. A low, safe electrical signal passes freely through fluids contained in lean tissue, such as muscle and blood, but meets resistance passing through fat tissue. The body analyser accurately measures the resistance and with reference to your personal data use it to calculate elements of body composition.

2. How to use

If possible, the measurement should be done undressed but always barefoot.

By nature, a body is subject of fluctuations (for example, loss of water after taking exercise or after a sauna visit, after a meal, etc.). To enable comparable readings it is important to take the measurements as possible always under the same conditions.

In order to ensure that the results of analysis are accurate and consistent, please keep the measurement conditions constant always at the same daytime. In the morning, directly after you've woken up, your body will be dehydrated and also the majority of fluid will be stored in the central trunk area. This means that the resistance is relatively high because of the poor conductivity in the body. By intensify moving during the day progresses the fluid becomes more evenly distributed through the limbs and increasing the accuracy of the readings. To get a realistic result it is important to take your readings at the same time and under the same conditions every day. The easiest way to stick the rule, measure always in the morning, 15 minutes after you've got up, either before or after you've gone to the bathroom.

In spite of a very low electrical signal, this body analyser is not suitable for persons with heart pacemaker or other electronic medical implants! There is no risk for persons with none electronic implant for instance a titanium plate in the knee. However, metal conducts the electric current extremely well and therefore the scale implicates the body fat value beautified means the actual body fat value is higher as indicated. However, tendencies may be determined as well.

Due to menstrual cycle and hormonal changes women experience greater changes in their hydration level. Retaining fluid may cause the weight to fluctuate day-to-day. This

7. Technical Data

Capacity x graduation: max. 150 kg x 100 g

Display resolution: body fat: 0.1%

Display resolution: body water: 0.1%

Display resolution: muscle mass: 0.1%

Display resolution: bone mass: 100 g

Personal memory loc.: 10 positions

Age: 10 80 years

Body height: 100 220 cm

Dimensions: approx. 230 mm x 130 mm x 21 mm

Battery: 1 x CR2032 (included)

Subject to technical modifications

8. Warranty

ADE warrants for a period of 3 years from the date of purchase that it will remedy any defects due to faulty material or workmanship free of charge by repair or replacement. When purchasing, please have the warranty coupon signed and stamped by the dealer. When making a guarantee claim, please return the weighing scale together with the guarantee card including the reason of complaint to your dealer.

CE-Conformity. This device features radio interference suppression in compliance with valid EC Regulation 2004/108

Note: The displayed value may be adversely affected under extreme electromagnetic influences, e.g. when using a radio unit in the immediate vicinity of the device. Once the interference has been rectified, the product can once again be used for its intended purpose. The device may have to be switched-on again.

Statutory instructions on battery disposal

Batteries must not be disposed as household waste. The law requires that you, as consumer, return the waste batteries either to public collection points in your town or village or to any outlet selling batteries of the same kind.

Note:

Batteries are marked as follows:

Li Battery contains Lithium

AI = Battery contains Alkali

Mn = Battery contains Manganese

CR (Li); A (Al, Mn); AA (Al, Mn); AAA (Al, Mn)

The average total body water percentage range for healthy men is between 50 - 65%. The equivalent value for women is approximately 45 - 60% due to the higher body fat content. About two third of the total body water is stored in the coils and is therefore called intra cellular. The other third of the total body water is extra cellular body water.

Women
AGE	Body Fat	Body Water
slim normal			sightly overweight	overweight	normal
10-16	<18%	18-28%	29-35%	>35%	57-67%
17-39	<20%	20-32%	33-38%	>38%	47-57%
40-55	<23%	23-35%	36-41%	>41%	42-52%
56-85	<24%	24-36%	37-42%	>42%	37-47%
Men
AGE	Body Fat				Body Water
	slim normal		sightly overweight	overweight	normal
10-16	<10%	10-18%	19-23%	>23%	58-72%
17-39	<12%	12-20%	21-25%	>25%	53-67%
40-55	<13%	13-21%	22-26%	>26%	47-61%
56-85	<14%	14-22%	23-27%	>27%	42-56%

There are no validated standards for muscle mass.

6. Error Messages

Err1 Overload - The weight exceeds the maximum capacity of 150 kg. Please immediately remove the critical load to avoid load cell damage.

Err = Incorrect weighing process - For example, the scale is placed unstable or you do not remain stationary on the weighing platform.

Incorrect measuring process at body fat analysing If body fat is lower than 5% or higher than 75% .

Battery is used up Please replace the battery with the intended type (1 x CR2032).

will also affect the body fat percentage readings. If the hydration level is high, the body will also affect the body fat percentage readings. If the hydration level is high, the body fat percentage is slightly less a loss hydration level means the body fat percentage is slightly higher.

There is no healthy risk for pregnancy. The body analyzer is absolutely safe for the mother and her unborn baby. However, due to the changes in water content in the mother's body, the readings should not be interpreted as completely accurate.

ADE Germany takes no responsibility for any damages or losses caused by the use of this body analyzer scale or for Third Party claims. This product is exclusively intended for private use. This product is not designed for commercial or professional use in hospitals or other medical facilities.

3. Commissioning

Safety guidelines:

The appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless a person responsible for their safety has given them supervision or instruction concerning use of the appliance. Children should be supervised to ensure that they do not play with the appliance.

Not suitable for persons with electronic implants (heart pacemaker, etc.).

Place the scale on a plane and firm surface (tiles, hardwood flooring, etc.) to avoid a wrong measurement on carpeted floor

Attention - Hazard of slips! Do not stand on the scale with wet feet or on a slippery surface of the weighing platform.

Please care that no heavy object may fall on the scale. The glass surface is breakable.

Clean the scale only by using a slightly damp cloth. Do not use solvents or abrasive cleaning agents. Do not submerge the scale under water.

Preparation:

Open the battery cover at the bottom side of the scale and insert the supplied battery (1 x CR2032). Please ensure the correct polarity of the batteries (+/-).

Extract the display, which is located beneath the weighing platform. To switch-on / switch-off the scale you will find a little black ON/OFF-switch at the underside of the scale.

Automatic switch-on / switch-off the scale

If the scale is switched-on and the indicated value does not change within approx. fifteen seconds, the scale automatically switch-off. To switch-on the scale again it is sufficient to touch lightly a corner of the display.

Units of weight:

There is a little push button UNIT at the bottom of the scale on the right beside the ON/OFF-switch for country specific setting with the option to switch from kg = kilogram to lb = pound or to st: lb = stone pound. Please pay attention to use the scale under consideration of your country specific unit of weight.

4. Programming / Enter of personal data

Before first time use your personal data like gender (male or female), body height and age must be programmed and saved under selected locations P0 P9 (up to 10 persons). The scale is equipped with highly sensitive touch buttons. The touch buttons are located above the display. To enter your personal data please utilise the buttons: SET (on and save button), (plus button), (minus button) and follow the particular points:

1. Touch lightly a corner of the display. The display indicates flashing P0 . To select your personal location (P0 P9), touch the or -button. After the selection of your personal location, touch the SET-button to save the reading.
2. After you we selected your personal location (e.g. P3), the symbol for gender starts to flash. To select the requested gender (▼ male or ▼ female), touch the ▲- or ▼-button. After the selection of your gender, touch the SET-button to save the reading.
3. After you've selected your gender (e.g., female), the symbol for body height (default 165 cm) starts to flash. To enter your body height, touch the or -button. After the selection of your body height, touch the SET-button to save the reading.
4. After you were selected your body height, the symbol for age (default age 25) starts to flash. To enter your age, touch the or -button. After the selection of your age, touch the SET-button to save the reading.

After input completion, the display indicates --- and the scale returns to 0.0 kg.
Shortly after, the scale automatically powers off.

To enter personal data of further persons please repeat the steps listed below.

5. Body Analysis

An analysis is only possible in bare feet. Your personal data must be entered first (please see page 4).

1. Switch on the scale by using the Tap-on-function. For this, step short with your foot on the scale. First, the display indicates the personal data of the last allocation and a few seconds later 0.0 kg. If they are not your personal data please select your personal memory location (where your personal data are stored) by using the or -key. Your personal data will indicate and then the scale returns to 0.0 kg.
2. Now, carefully step in bare feet on the right and left stainless steel electrodes (measuring units) of the scale and remain stationary.

3. At first, your weight will indicate on the display. Shortly after, while the analysis is taking place, the signal o starts to move in the display. Still remain stationary on the scale. After completion of the measurement, your measured values will be shown as follows:

4. Your body fat in % and as subtitle an evaluation;
   (-) insufficient body fat - (0) healthy (+) too much body fat (++) obese

5. Your body fat in %
   3.Your muscle mass in %
6. Your bone mass in kg

After a few seconds the scale switch-off automatically.

The body fat content is shown as the amount of stored fat as a percentage of total body weight. There is no generally accepted set value as this varies significantly according to gender (due to the different build) and age. Body fat is vital for basic body functions. It's protecting organs, cushioning joints, regulating body temperature, storing vitamins and serves the body as energy storage.

As essential for women a minimum body fat proportion between 10% and 13% and for men between 10% and 13% is requested - with the exception of competitive athletes.

Body fat is not a clear indicator for health. Too high body weight and a too high body fat proportion are linked to the incidence of many civilization diseases such as diabetes, cardiovascular diseases, etc. Lack of movement and improper nutrition are often the prime course for these diseases. There is an obvious direct relationship between overweight and lack of movement.

A significant part of the human body consists of body water. This body water is differently distributed throughout the whole body. Lean muscle tissue contains approx. 75% body water, blood approx. 83% body water, body fat approx. 25% body water and bones have a water content of about 22% .

MUSCOLAR
MASSA OSSEA

Indices
