USER MANUAL FRESHWINE2 LA SOMMELIERE

Please read this instruction carefully before use

Wine cooler Instruction

IMPORTANT SAFEGUARDS

• Read this instruction carefully before use.
• Make sure the voltage in your living area is corresponding to the one shown on the rating label of appliance.
• If the power cord was damaged or the appliance has malfunction, do not use it and send it to the nearest service agent.
• To prevent electric shoot, do not immerse the appliance or power cord plug in water or other liquid.
• Unplug the appliance before cleaning or when it is not in use.
• To avoid affecting ventilation, make sure the ventilating opening must keep a certain distance (about 80~cm ) from other articles when the appliance is operating.
• The attachments not recommended by manufacturer can not be used.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  Children should be supervised to ensure that they do not play with the appliance.
• Do not place this product near electrical burner or hot burning gas, to avoid accident.
• Do not use outdoors.
• Do not clean this appliance with chemical scour or hard tools.
• Unplug the appliance immediately after operation.

Switching Power Supply Model: QL-08011-B1205000F,INPUT:AC 100-240V 50/60Hz 1.5A OUTPUT:12V 5000mA, Do not be replaced other one

Save these instructions.

• Isolated power adapter can be powered by AC(100-240V/50/60Hz)
• Mechanical control, with rotary temperature adjust knob, easy in operation
• This appliance is portable and lid can be opened by pressing button, it is convenient for use.
• The clarity windows at the top is great to see your bottles

PRODUCT SPECIFICATIONS

No.	Item	Parameters
1	Model	FRESHWINE FRESHWINE2
2	Spec.	AC: 100-240V/50/60Hz; DC: 12V
3	Power supply for AC	✓
4	available capacity	1 Bottle
5	rating power	60W
6	power for keeping warm	Switch off after reaching 7℃/switch
7	refrigeration performance	7±2℃(tested at 25℃)
8	noise	35dB(A)
9	Radiating mode	refrigerating directly
10	adjustable thermostat	temperature range: 7℃~18℃
11	With power indicator	✓
12	dimension(W×D×H)	290X172X253MM
13	net weight	1.68KG

• Put appliance on counter, then insert the DC end of adapter into the receptacle on the back of appliance, and insert the other end of adapter into the power socket.
• Press the front button to open top lid, put a bottle of red wine or white wine (about 750mL ) in it, notice that the bottom of bottle should contact the AL radiator well, to get the best refrigeration: Then lock top lid.
• Turn the front knob, When out of OFF position, power indicator will illuminate, the appliance is started-up. There are four settings which are OFF-MIN-MED-MAX, temperature will get lower when turn the knob in clockwise direction, whereas get higher. You can turn the knob to get your intended temperature. please see the temperature table
• This appliance can be take out ease, and can be fix into automobile socket, the operation procedure is same to above content
• Cleaning: When not in use, plug out the adapter, open the top lid, then discard the condensation water in the appliance, wipe the appliance with clean soft and dry cloth. Prevent the appliance from moulding and smelling.
• You may store this wine cooler in carton box when not in use.

Mechanical thermostat can be setting between min and max position, to help you choosing temperature, here are temperature which correspond to different position (this can change according to your ambient temperature and conditions):

Off : the cooler stop working

Min : 15- 18°C

Med : 12- 15°C

Max: 7-10°C

This wine cooler is a semiconductor refrigerating product, can store a bottle of wine (750 mL), have cooling and keeping warm functions, and the temperature setting is adjustable. Adopt 100-240V wide voltage outer adapter, can match with DC power cord, so the appliance can be powered with both AC power and DC power; use AL radiator which radiating mode is refrigerating directly.

Correct Disposal of this product

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal,recycle it responsibly to promote the sustainable reuse of material resources.To return your used device,please use the return and collection systems or contact the retailer where the product was purchased.They can take this product for environmental safe recycling.

LA SOMMELIERE INT.

ZA LES PORTES DE L'OCEANE OUEST BP16

72650 SAINT SATURNIN

www.lasommeliere.com
