USB Slim Ergonomic Multimedia Keyboard Quick Installation Guide

Introduction

The USB Slim Ergonomic Multimedia Keyboard is a ergonomic designed USB keyboard with integrated palm/wrist rest to provide a more comfortable typing environment.

Key Features and Benefits

• Contemporary ultra slim appearance with integrated palm rest
- QWERTY keyboard layout with numeric keypad provides more productive typing
• 16 hot keys provides quick access to internet, e-mail, and multimedia control
• Durable laser printed keys can last up to 10 million keystrokes
- Adjustable tilt legs for the perfect ergonomic fit

Package Contents

- USB Slim Ergonomic Multimedia Keyboard

System Requirements

• PC computer with an available USB port
- Windows ^ 8 (32-/64-bit) / 7 (32-/64-bit) / Vista (32-/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / Server 2008 R2 / Server 2012

Specifications

• Keyboard type: USB wired multimedia keyboard
• Compliant with USB 1.1 specification
• Keyboard feature: Ergonomic design
  • Number of keys: 103 keys with 16 multimedia hotkeys
• Wired USB cable length: up to 4.32 ft
  • Key press force: 44g +/- 6g
  • Key switch life: \~ 10 million cycles
• Working Voltage: 5V
  • Working Current: 55mA
• Dimensions: 16.73"(L) x 7.28"(W) x 0.68"(H)

Layout

1-12 13-16 20 21 17-19 Integrated palm/ wrist rest

Figure 1: Front Layout

22 22 I/O® Organic Multimedia Keyboard

Figure 2: Rear Layout

Hotkey Applications

Refer to the image below for the positions and definitions of each hotkey. Enable the hotkey function by simply pressing the key.

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

1. Sleep mode: Switch the system into sleep mode. Press the Sleep mode hotkey again to resume from sleep mode

NOTE: Sleep mode hotkey has no function in Windows Server 2003 & 2008 (32-/64-bit)/2008 R2/Server 2012.

1. Home page: Starts your default Web browser and loads the home page
2. Web back: Return to previous webpage
3. Web forward: Go to the next webpage
4. Web stop: Stop loading the current webpage
5. Media player: Run your default media player
6. Mute: Mutes system sound
7. Volume down: Decreases system sound
8. Volume up: Increases system sound
9. Previous: Switch to the previous media Track
10. Play/Pause: Switch between playing and pausing the media player
11. Next: Switch to the next media track
12. My Computer: Same as double click Computer or My Computer on desktop

NOTE: The My Computer key has no function under Server 2003.

1. Calculator: Start Microsoft calculator
2. Email: Starts default email program
3. Search: Opens the search box

LED Indicators

1. Num Lock LED indicator: Num Lock LED is on the numeric keys are enabled; LED off the numeric keys are disabled
2. Caps Lock LED indicator: Caps Lock LED on letters will be typed uppercase; LED off letters will be typed lowercase
3. Scroll Lock LED indicator: Scroll Lock LED on all scrolling features are locked

Others

1. Windows key: Same as clicking Start button on the Windows tool bar
2. Menu key: Same as right mouse button
3. Snap open legs: Adjusts tilt angle of the keyboard for the best ergonomic fit

Technical Support and Warranty

QUESTIONS? SIIG's Online Support has answers! Simply visit our web site at www.siig.com and click Support. Our online support database is updated daily with new drivers and solutions. Answers to your questions could be just a few clicks away. You can also submit questions online and a technical support analysts will promptly respond.

SIIG offers a 2-year manufacturer warranty with this product. This warranty covers the original purchaser and guarantees the product to be free of any defects in materials or workmanship for two (2) years from the date of purchase of the product.

SIIG will, at our discretion, repair or replace (with an identical product or product having similar features and functionality) the product if defective in materials or workmanship. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Please see our web site for more warranty details.

If you encounter any problems with this product, please follow the procedures below. A) If it is within the store's return policy period, please return the product to the store where you purchased from.

B) If your purchase has passed the store's return policy period, please follow the steps below to have the product repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.

Step 2: After obtaining an RMA number, ship the product.

• Properly pack the product for shipping. All accessories that came with the original package must be included.
• Clearly write your RMA number on the top of the returned package. SIIG will refuse to accept any shipping package, and will not be responsible for a product returned without an RMA number posted on the outside of the shipping carton.
• You are responsible for the cost of shipping to SIIG. Ship the product to the following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

RMA #: ____

- SIIG will ship the repaired or replaced product via Ground in the U.S. and International Economy outside of the U.S. at no cost to the customer.

About SII G, Inc.

Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity solutions (including Serial ATA and Ultra ATA Controllers, FireWire, USB, and legacy I/O adapters) that bridge the connection between Desktop/Notebook systems and external peripherals. SIIG continues to grow by adding A/V and Digital Signage connectivity solutions to our extensive portfolio.

SIIG products offer comprehensive user manuals, many user-friendly features, and are backed by an extensive manufacturer warranty. High quality control standards are evident by the overall ease of installation and compatibility of our products, as well as one of the lowest defective return rates in the industry. SIIG products can be found in computer retail stores, mail order catalogs, through major distributors, system integrators, and VARs in the Americas and the UK, and through e-commerce sites.
