LVT 6 I - Dishwasher Saivod - Free user manual and instructions

Product Type	Built-in Dishwasher
Brand	Saivod
Model	LVT 6 I
Width	60 cm
Height	85 cm
Depth	60 cm
Weight	50 kg
Place Settings	6
Energy Efficiency Class	A+
Annual Energy Consumption	260 kWh
Water Consumption per Cycle	9.5 L
Noise Level	49 dB(A)
Number of Programs	6
Program Types	Eco, Intensive, Normal, Quick, Rinse, Soak
Drying System	Condensation drying
Number of Temperature Settings	4
Delay Start	Up to 24 hours
Safety Features	AquaStop, Child lock, Overflow protection
Interior Material	Stainless steel
Control Type	Electronic buttons with LED display
Adjustable Feet	Yes, front and rear
Spare Parts Available	Filters, spray arms, door hinge, drain hose, inlet hose, control board

Frequently Asked Questions - LVT 6 I Saivod

How to install the Saivod LVT 6 I dishwasher?

Ensure the dishwasher is placed on a level surface. Connect the inlet hose to a cold water supply (max 60°C) with a 3/4 inch threaded connection. Connect the drain hose to a siphon or sink drain. Plug into a grounded outlet. For built-in installation, follow the cabinetry dimensions in the manual.

What do the error codes mean?

Common codes: E1 (water intake issue), E3 (heating problem), E4 (overflow). Refer to the manual for detailed diagnostics. Often turning off the power and restarting resolves temporary errors.

How to clean the filter?

Turn off the dishwasher and remove the lower spray arm. Unscrew the cylindrical filter (turn counterclockwise). Rinse under running water. Use a soft brush if needed. Reassemble monthly for optimal performance.

Why is my dishwasher not drying dishes?

Check that rinse aid is filled and the setting is correct. Ensure the drying cycle is selected (e.g., Eco may have less drying). Also verify that the heating element is working and the fan is not blocked.

Can I use regular dish soap?

No, only use dishwasher detergent (powder, gel, or tablets). Regular dish soap creates excessive suds, causing leaks and poor performance. Use rinse aid for better drying.

How to reset the dishwasher?

Press and hold the Start button for 3 seconds to cancel a cycle. For a full reset, turn off the power at the circuit breaker for 1 minute, then restore power.

What is the maximum load capacity?

The Saivod LVT 6 I can hold up to 6 place settings. Load plates facing the center, cups on upper rack, and utensils in the basket. Do not overload.

How to replace the inlet hose?

Turn off water supply and disconnect old hose. Use a new hose (rated for dishwasher, min 1.5 m). Ensure rubber gasket is in place. Tighten connections by hand plus a quarter turn with a wrench. Check for leaks.

Why does the dishwasher leak water?

Common causes: loose hose connections, damaged door seal, overfilling due to faulty float switch, or clogged drain. Inspect hoses, clean filter, and ensure the door closes tightly.

How to maintain the dishwasher?

Monthly: clean filter and spray arms. Every 3 months: run a maintenance wash with dishwasher cleaner or a cup of vinegar on empty hot cycle. Check and clean the door seal regularly.

USER MANUAL LVT 6 I Saivod

Cutaway view of a kitchen appliance showing internal components like dish, sink, and rack (no text or symbols visible)

Diagram of a mechanical or electrical component with an upward arrow indicating motion (no text or symbols present)

Close-up of a mechanical component with a lever and base plate (no visible text or symbols)

Illustration of a hand holding a plug with arrows indicating internal components (no text or symbols)

Illustration of a hand pressing a button on a device (no text or symbols visible)

Close-up of a mechanical component being inserted into a housing, showing internal parts and a tool (no text or symbols visible)

El indicador visual Oscuro = suficiente Rinse-Aid Claro = agregue Rinse-Aid

Diagram of a handheld electronic device with labeled component 'C' (no text or symbols beyond label)

Información de uso

Hand holding a circular mechanical knob with a curved arrow indicating rotation (no text or symbols)

Illustration of a funnel pouring liquid into a container with particles (no text or symbols)

8

E

Tempo de Demora / Tempo resante 888 Find second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second second seconds perade 5.0 Rosc 7/2 Rotor perade Rotor indicadores perade Rotor indicadores perade Indicator de sal Indicator de brillantador Indicator de brillantador (on/off) On / Oil

Corporate of Level 11

888 PCA/PSA

Diagram of a hand operating a mechanical device inside a wire cage (no text or symbols visible)

Technical diagram of a structural frame with numbered components and directional arrows indicating motion or force

Diagram of a wire mesh basket with arrows indicating direction (no text or symbols)

Mechanical assembly diagram showing two stages of a mechanical component with rotating parts and directional arrows (no text or labels)

Hand holding a wire mesh component with an arrow indicating rotation (no text or symbols)

(si está provista)

Three-panel illustration showing a building interior with structural elements and a hand holding a tool, no text or symbols present.

Four technical diagrams showing wireframe and 3D model views of a basket-like structure, labeled A, B, C (no text or symbols on the models themselves)

Diagram showing two stages of a mechanical device with labeled arrows indicating motion or assembly steps.
