Lillian - Gitarreneffektpedal Walrus Audio - Kostenlose Bedienungsanleitung

Produkttyp	Analoges Phaser-Effektpedal
Marke	Walrus Audio
Modell	Lillian
Abmessungen (ca.)	12,5 cm x 6,5 cm x 3,5 cm
Gewicht (ca.)	400 g
Stromversorgung	9 V DC, Mittelpol negativ, 2,1 mm Hohlstecker, 100 mA
Batteriebetrieb	Nicht unterstützt (nur Netzteil)
True Bypass	Ja
Regler	Rate, Depth, Feedback (Regler); Love (Kippschalter, 2 Stellungen)
Anschlüsse	6,35 mm Klinke: Input, Output; 2,1 mm DC-Buchse
Gehäusematerial	Metall (Druckguss)
Besonderheiten	Vintage-Phaser-Sound, Love-Schalter für alternative Klangcharakteristik
Anzeige	LED zur Betriebsanzeige (leuchtet bei aktiviertem Effekt)
Reinigung	Mit einem trockenen oder leicht feuchten Tuch abwischen, keine aggressiven Reinigungsmittel verwenden
Lagerung	An einem trockenen, staubfreien Ort bei Raumtemperatur
Sicherheitshinweis	Nur mit dem mitgelieferten oder einem kompatiblen Netzteil betreiben; Gerät vor Feuchtigkeit und extremen Temperaturen schützen
Reparierbarkeit	Potentiometer und Schalter können von einem Fachmann ausgetauscht werden; keine verschweißten Akkus
Mitgeliefertes Zubehör	Bedienungsanleitung, Aufkleber
Garantie	Lebenslange Garantie auf Herstellungsfehler (nach Registrierung)

Häufig gestellte Fragen - Lillian Walrus Audio

Wie schließe ich die Lillian an mein Gitarren-Pedalboard an?

Warum leuchtet die LED nicht?

Kann ich die Lillian auch mit einer Batterie betreiben?

Was bewirkt der Love-Schalter?

Wie reinige ich die Lillian richtig?

Ist die Lillian True Bypass?

Warum höre ich kein Signal, wenn der Effekt aktiviert ist?

Welche Stromversorgung wird empfohlen?

Kann ich mehrere Lillian-Pedale miteinander verbinden?

Gibt es eine Garantie auf die Lillian?

BEDIENUNGSANLEITUNG Lillian Walrus Audio

Bypass LED —

Bypass Switch —

supply is recommended for powering all Walrus Audio Pedals. Main power supplies are not recommended.

WALRUS

AUDIO

WALRUSAUDIO.COM

Cot questions or need a repair or want to mail us some cookies? Email [e-mail]

All our pedals come with a limited lifetime warranty. walrusaudio.com/pages/warranty-and-repair for more info.

LILLIAN ANALOG PHASER

During WWII, from 1943-1944, over 1,000 women volunteered to fly in the military to help while so many men were away fighting. This program was called W.A.S.P. (Woman Air Force Service Pilots). One specific pilot, Lillian Yonally, inspired us with her story of traversing dangerous skies. From there, the idea of the Lillian Analog Phaser was born.

The Lillian is a true bypass, all analog, multi-stage Phaser drawing control layout inspiration from the Julia Chorus. With controls like Rate. Width, Feedback, and D-P-V blend, the Lillian is packed with a wide array of analog phaser goodness waiting to be dialed in: The 'Stages' switch allows the user to select 4 or 6 stages which alters the overall voice of the effect from warm and tight phasing with 4 stages to a more complex filtered sound with 6. The D-P-V knob lets these be blurred and vibrato sounds allowing for a wide range of control over the intensity and type of effect. Top mounted input, output, and power jacks as well as soft switch relay bypassing make the Lillian fit well on your board and ensure smooth operation for years to come.

CONTROLS

RATE

Set the speed at which the LFO sweeps. From little or no movement at lower settings, to crazy whirling phase.

WIDTH

Controls the frequency range that the filters sweep through. Set low for a narrow range and a less dramatic effect, or higher for a wider range resulting in more defined phaser tones.

FEEDBACK

Determines how much of your phase shifted signal gets sent back through the filter stages. Set this control lower for more traditional phaser tones, and higher for more of a resonate filter sound.

D-P-V

Blend between Dry, Phase Shifted, and Vibrato (labeled d-p-v on the pedal). The Dry-Phase-Vibrato blend changes the ratio of dry to wet signal sent to the output. At minimum, you will hear no effect. Set it to noon for equal parts dry and wet – the traditional Phaser setting.

D-P-V CONTINUED

Set it to maximum for 100% wet resulting in pitch vibrato. Explore the ground between minimum and noon for adding slight amounts of movement to your dry signal and the area between noon and maximum for all sorts of unheard phase/vibrato combinations.

STAGES SWITCH

Allows the user to select 4 or 6 stages which alters the overall voice of the effect from warm and tight phasing with 4 stages to a more complex filtered sound with 6. Each pair of stages creates a notch filter and a certain frequency range that the LFO sweeps through. This means, in 4 stage mode, there are 2 swept filter notches, and in 6 stage mode there are 3 swept notches. They each have their own "voice", so flip the switch and have fun!

SMART MOMENTARY BYPASS SWITCH

When the bypass switch is in the off position, press and hold to temporarily activate the effect. Releasing the switch turns the effect off.
