Produkttyp	Kompakter Live-Switcher
Marke	Panasonic
Modell	AV-HSW10
Videoauflösung (3G-SDI)	1080/59.94p, 50p, 29.97p, 25p, 24p, 23.98p; 1080/59.94i, 50i; 720/59.94p, 50p
Videoauflösung (NDI)	1080/59.94p, 50p, 29.97p, 25p, 24p, 23.98p; 720/59.94p, 50p
Videoauflösung (NDI|HX)	1920x1080p, 1280x720p
Videoeingänge (Basisband-Modus)	4x 3G-SDI, 1x HDMI
Videoeingänge (IP-Modus)	3x NDI/NDI|HX/SRT (max. 2 NDI|HX/SRT)
Videoausgänge (Basisband)	2x 3G-SDI, 1x HDMI
Videoausgänge (IP)	2x NDI/NDI|HX/SRT/RTMP
USB-Videoausgang	1x USB Typ-C (USB Video Class)
Audioeingänge	2x RCA (Cinch)
Audioausgänge	1x 3,5 mm TRS-Klinke
Keyer	2 Kanäle (PinP, Linear Key, Luminanz-Key, Chroma-Key)
MultiViewer	Bis zu 16 geteilte Bildschirme, 10 wählbare Muster
Genlock	BB oder Tri-Level (Eingang/Durchschleifausgang)
Frame Synchronizer	Für alle Eingänge
PTZ-Link	Switcher Link, TSL5.0
Shot Memory	Max. 12 Voreinstellungen
USB-Anschlüsse	1x USB Typ-A (USB-Speicher), 1x USB Typ-C (UVC)
Stromversorgung	45 W (Netzadapter extern, nicht im Lieferumfang)
Abmessungen (B x H x T)	254 mm x 175 mm x 67 mm
Fernsteuerung	Software Control Panel über Netzwerk-PC
Besondere Merkmale	10-Bit-Verarbeitung, OSD, Silikontasten mit konkavem Design

Häufig gestellte Fragen - AV-HSW10 PANASONIC

Was ist der Panasonic AV-HSW10?

Welche Videoformate unterstützt der AV-HSW10?

Wie viele Videoeingänge hat der AV-HSW10?

Kann der AV-HSW10 direkt auf Streaming-Plattformen senden?

Was ist NDI und benötige ich eine Lizenz?

Wie kann ich den AV-HSW10 mit einem Computer steuern?

Welche Keyer-Funktionen bietet der AV-HSW10?

Wie funktioniert der MultiViewer?

Unterstützt der AV-HSW10 USB-Video für Webkonferenzen?

Welche Abmessungen und Leistungsaufnahme hat der AV-HSW10?

BEDIENUNGSANLEITUNG AV-HSW10 PANASONIC

Panasonic CONNECT

AV-HSW10

Compact Live Switcher

Scheduled for release in the fourth quarter of CY2023

Preliminary

Broadcast-quality video in a compact, notebook-size chassis.

Supports diverse IP protocols for smooth IP-based video production and distribution

Conveniently Compact Switcher Achieves High-quality Video

The AV-HSW10 supports 10bit processing for broadcast-quality video and is also equipped with diverse functions necessary for high-quality video production, such as a frame synchronizer, Genlock, and various keyers. It also supports audio input, enabling switching between video and audio with a single unit. The AV-HSW10 takes video broadcasting to the next level, making it perfect for highly professional online lectures, corporate webinars and other live events that are gaining momentum these days.

Signal Format

3G-SDI	1080/59.94p,50p,29.97p,25p,24p,23.98p1080/59.94i,50i720/59.94p,50p
NDI**1*2	1080/59.94p,50p,29.97p,25p,24p,23.98p720/59.94p,50p
NDI*|HX*1*2	1920x 1080p,1280x 720p

Diverse Interfaces to Suit Wide-ranging Needs

In addition to 3G-SDI and HDMI, the AV-HSW10 supports NDI ^*12 as well as SRT and many other IP transmission standards to suit contemporary video-production needs. When combined with IP-enabled PTZ cameras, it creates a simple IP-based video production system. It also supports RTMP for direct upload to streaming services, and USB Video Class for compatibility with web conferencing services. The system can be adjusted based on the particular platform and site layout, enabling one-person operation from production to distribution.

Video Input

	Baseband mode		IP mode
3G-SDI	4	3	1
HDMI	1	2	1
IP (NDI ^※ * ^1*2 /NDI ^® |HX ^*1*2 /SRT)	2		3*3

Video Output

3G-SDI	2
HDMI	1
IP (NDI ^1*1*2 /SRT/RTMP)	2
USB Video Class	1

Simple, Intuitive and Reliable Operation

The AV-HSW10 offers the simple, intuitive operability required in live production and ensures easy, error-free operation - all in a robust chassis design. The main unit features buttons and a fader - inspired by its predecessor, the AW-HS50, and have been enhanced for even greater operability essential for high-quality video distribution. On-screen display (OSD) also is supported.

The tactile-response crosspoint button is made of soft silicon rubber and features a concave design for extra-easy, no-look use.

Diverse Keyers for More Attractive Videos MultiViewer with 10 Selectable Patterns

Two channels of keyers can be programmed for PinP, linear, luminance or chroma key ^4 enabling high-quality compositing achievable only with 10bit signal processing. Two AUX buses are also provided.

Webinar screen example with keyer

MultiViewer output is provided as standard, enabling up to 16 split screens to be displayed on a single screen. Split-layout options include 4, 5 (2 patterns), 6 (2 patterns), 9, 10 (2 patterns), 12 and 16 screens.

12-split MultiViewer screen

Remote Control with Software Control Panel\*5

The AV-HSW10 is compatible with Panasonic's Software Control Panel*5 for video monitoring and switching with a networked PC. MultiView images can be checked remotely to divide up production tasks for greater on-site efficiency in the field.

Software Control Panel screen (sample)

*1: NDI® is a new protocol developed by NewTek, Inc. that supports IP video production workflow. NDI® is a registered trademark of NewTek, Inc. in the United States and other countries. In this instance, NDI® is used to indicate low latency with high bandwidth NDI®, NDI®|HX is used to indicate high efficiency low bandwidth NDI®|HX. *2: Requires a separate license (paid option). Please contact Panasonic sales representative for details. *3: NDI®|HX and SRT have a maximum of 2 inputs. *4: Chroma key can only be selected from keyer 1. *5: Future support scheduled. Note: Product images shown are CG images. Screen examples for illustration purpose only. Information subject to change without notice.

AV-HSW10 actual size

Note: CG image

Ex.1 Lecture or live event

For hybrid, in-person and online events, large-screen video at the venue can be output via 3G-SDI or HDMI and easily broadcast to remote locations via IP.

Ex.2 Webinar or teleconference

USB Video Class is supported for streaming to a web conferencing service, such as Teams or Zoom, without having to install a special driver on the PC.

Ex.3 Video streaming

The AV-HSW10, also a great option for broadcasting prerecorded video, supports RTMP for direct uploading to video-sharing platforms such as YouTube.

Rear ViewSystem Examples

Specifications

		Baseband mode	IP mode
Video Input	3G-SDI	4 or 3	1
	HDMI	1 or 2	1
	NDI ^|**1 × 2| /Streaming	2	3
Video Output	3G-SDI	2	2
	HDMI	1	1
	NDI ^|**1 × 2| /Streaming	2	2
Video Format	3G-SDI	1080/59.94p,50p,29.97p,25p,24p,23.98p1080/59.94i,50i720/59.94p,50p
	NDI ^|**1 × 2|	1080/59.94p,50p,29.97p,25p,24p,23.98p720/59.94p,50p
	NDI ^® |HX ^*1 × 2|	1920 x 1080p, 1280 x 720p
Audio		IN: RCA x 2, OUT: Φ 3.5 mm TRS
Frame Synchronizer		All inputs
CC/UC/DC		i/P converter,DC/UC (1080-720P), CC

Keyer	2 (PinP, Linear key, Luminance key, Chroma key)
AUX	2
USB Video Class Output	USB Type-C, 1ch
Genlock	BB or Tri-level (Input/through output)
PTZ Link	Switcher Link, TSL5.0
VMEM	Still x 2
Shot MEM	Max. 12 presets
USB	USB-Type A x 1 (USB Memory)
Dimensions (W x H x D)(excluding protrusions)	254 mm x 175 mm x 67 mm(10 inches x 6-7/8 inches x 2-5/8 inches)
Power Consumption	45 W (TBD)

Dimensions

Unit: mm (inches

*1: NDI® is a new protocol developed by NewTek, Inc. that supports IP video production workflow. NDI® is a registered trademark of NewTek, Inc. in the United States and other countries. In this instance, NDI® is used to indicate low latency with high bandwidth NDI®, NDI®|HX is used to indicate high efficiency low bandwidth NDI®|HX. *2: Requires a separate license (paid option). Please contact Panasonic sales representative for details.

Panasonic Connect Co., Ltd.

2-15 Matsuba-cho, Kadoma, Osaka 571-8503 Japan

Specifications are subject to change without notice.
