BRUGSANVISNING WG3010 CLARION
clarion
WG 3010
12" (30.5cm) SUBWOOFER
| Electrical Specifications | |
| Maximum Musical Input Power | 900W F |
| Continuous Input Power | 300W V |
| Sensitivity | 83dB |
| Impedance | 4 ohms |
| Thiele / Small Electromechanical Parameters | ||
| o | Resonance Frequency | 23Hz |
| as | Equivalent Stiffness | 64.3L |
| Qts | Total Electromechanical Dampening | 0.56 |
| Sd | Cone Area | 530.9 cm ^2 |
| Sealed Enclosure Recommendation | |
| V_b | Internal Area cu. ft. (liter) 1.25 (35.40) Internal Area cu. ft. (liter) |
| F_3 | -3dB Point (Hz) 40 -3dB Point (Hz) 28 |
| Qtc Enclosure Damping 0.81 Tuning Frequency (Hz) 32 | |
| H Height -inch (cm) | 14 (35.56) H Height -inch (cm) 13.5 (34.29) |
| W Width -inch (cm) | 24 (60.96) W Width -inch (cm) 16.5 (41.91) |
| D Depth -inch (cm) | 10 (25.40) D Depth -inch (cm) |
| Ported Enclosure Recommendation | |
| 2.0 V_b (56.63) | |
| F_3 | |
| F_b | |
| ) | 23 (58.42) |
| P | Port Diameter and Length -inch (cm) 4 x 13.2 (10.16x33.53) |
NOTE: Internal volume is measured before speaker and/or port displacement. External dimensions are based on the use of 3/4" (1.9cm) material. The port can be placed on any fitting face as long as the port ends are not obstructed. When using enclosures other than recommended, contact technical support or your local installation expert. Proper enclosure design is one of the key components to subwoofer performance and should be handled by experienced installers. Please contact your authorized Clarion dealer for the best results.
