BRUGSANVISNING Pro Diver 13699 INVICTA

PRESENTATION

Display Elements
Minute Hand
Hour Hand
Second Hand
Date

Illustration of a wristwatch with yellow dial and black wrist (no text or symbols)

Control Buttons

Crown Positions:

1. Normal position
2. Quick correction of date
3. Setting of hour, minute, date

INSTRUCTIONS

MANUAL

NH37A

SETTINGS

Set the Time, Hour, Minute

1.1 Pull the crown to position 3.
1.2 Turn the crown clockwise to set hour/minute hands to the desired time.
1.3 Push the crown back to position 1.

Yellow wristwatch with analog clock face and wrist strap (no visible text or symbols)

Yellow wristwatch with yellow dials and a small battery icon, no visible text or symbols on the device itself.

Yellow wristwatch with analog clock face and wrist strap (no visible text or symbols)

Set of Date

2.1 Set the crown to position 2.
2.2 Turn the crown clockwise step-by-step to the desired date.

2.3 Push the crown back to position 1.

!! Attention !! Do not set the date between 9:00PM and 4:00A.M. As this will cause a malfunction.

Yellow wristwatch with analog clock face and wrist strap, no visible text or symbols on the watch face itself

Yellow wristwatch with black dial and wrist strap, no visible text or symbols on the face or background

Yellow wristwatch with black dial and wrist strap, showing front and side views (no text or symbols)

INFO

To wind up the Mainspring

Manual winding – Fully wound up by turning the crown minimum 55 times

– Fully wound up by turning the ratchet wheel screw 8 times

Machine winding – Rotary speed: 30rpm
- Operation time: 60 mintues
