BRUGSANVISNING E-OF 1200 EINHELL
Router E-OF 1200
Art.-No.: 44.720.91
Bar code: 4006825528435
Sales unit: 4 pcs
This well-designed, handy electronic router incorporates an impact resistant plastic housing. The E-OF 1200 router is powerfull enough to use on wood, lightweight materials and plastics, for cutting slots, edges, profiles and elongated holes. The cutters can be simply changed by the integrated spindle lock. With the additional speed regulation the cutter frequency (speed) can be adjusted to the working material.
Features:
- Electronic speed control (1)
- Integrated dust extraction by adapter (2)
- Parallel guide (3)
- Spindle lock for easy cutter changing (4)
- Adjustable cutting depth with gun gauge (5)
- Clamping device ∅ 8 mm and ∅ 6 mm
- Housing surface “softpainted”
Technical data:
- Mains: 230 V\~50 Hz
- Power: 1200 watts
- Idle speed: 16,000 – 32,000 min
- Stroke height: 40 mm
- Clamping device: ∅ 8 mm and ∅ 6 mm
- for form millers max.: ∅ 36.5 mm
- Weight: 4.5 kg
- Packing dimensions: 320 x 160 x 240 mm
As special accessory available:
Router bit set
12 pcs
Art.-No.: 43.501.99
Bar code: 4006825431391
Mærke : EINHELL
Model : E-OF 1200
Kategori : Høvl
